LED Dance Floor Screen Of Interactive Radar System P3.91 500*1000mm Aluminum Cabinet
LED dance floor screen of interactive radar system p3.91 500*1000mm aluminum cabinet
Specifications
The Advantage of the Indoor Dance Floor LED Screen
1.Fully waterproof (can be washed directly with water), strong shock resistance, good slip resistance (the actor can jump on it at will, will not slip), the bearing capacity is large (the car can be directly crushed, the load point is 2 tons), A single box can fine-tune the height difference between the cabinets, the mask is PC+ composite material, has anti-UV function, can be exposed to the sun (the screen surface will not yellow), appearance beautiful, high definition, high brightness, good heat dissipation, Easy to install, soft and clear color.
2.One-screen multi-purpose: It can be used as color brick when tiling; it can be used as stage main screen or color screen when stacking or lifting.
3.This product can be upgraded to a sensor screen through sensor or infrared technology to interact with the audience.
| LED Module | ||
| pixel pitch | 3.91mm | |
| module size | 250*250mm | |
| module resolution | 64*64dots | |
| Arrangement form | Vertical row | |
| Scan | 1/16scan | |
| Application | Indoor | |
| Weight | 0.5KG | |
| LED Cabinet | ||
| Cabinet Size | 500*800mm*85 | |
| Cabinet resolution | 128*128 dots | |
| module quantity | 2*2pcs | |
| LED driver quantity | G-energy/Chuanglian/Meanwell/Youyi | |
| Material | Die casting aluminum | |
| Receiving card | 1pcs | |
| Weight | 15KG/PCS | |
| Load-bearinng | 2T/m³ | |
| LED Screen | ||||
| Pixel density | 65536dots/Sqm | Continuous Working Hours | >72 hours | |
| Ave power consumption | ≥230W/Sqm | Using Life | 100,000 hours | |
| Max power consumption | ≤800W/Sqm | MTBF | >10,000H | |
| Optimum Viewing Distance(m) | ≥4mm | Scatter OOC Point | <0.01% | |
| Brightness | ≥2200cd | Continuous OOC Point | None | |
| Refresh Rate | ≥1920 frame/s | IP Grade | IP45/IP30 | |
| LED Drive mode | Constant Current | Working Temperature | -35C----+60C | |
| Display color | 17M——69G | Working Humidity | 10---70% |
|
Applications:
This kind of LED SMD full color led display is appliled for displaying advertising, city beautifying,
information publicity, great concerns and relative activities.
