Big tunnel size 100cm(H)*100cm(W) Cargo X - Ray Luggage And Parcel Scanner
Big tunnel size 100cm(H)*100cm(W) Cargo X - Ray Luggage And Parcel Scanner
Standard X-Ray Generator and Image Performance –AT100100
|
Tunnel Size: |
1000(W)*1000(H)mm |
|
Conveyor Speed: |
0.22m/s |
|
Conveyor Max Load: |
200kgs |
|
Dose per Inspection: |
<1.7μGy/h |
|
Resolution: |
<0.101mm Metal Wire |
|
Steel Penetration: |
28mm Steel guaranteed; 32mm typical |
|
Optional High Pentration: |
38mm Steel guarantee; 40mm typical |
|
Resolution: |
38 AWG guarantee; 40 AWG Typical |
|
Generate direct: |
downward |
|
Generate angle: |
80 degree |
|
Anode Voltage: |
160Kv |
|
Anode power: |
0.4 to 1.2mA |
|
Cooling / Duty Cycle: |
Oil Cooling /100% |
Image System:
|
X-ray Sensor: |
L-Shaped Photodiode Array (mono-energetic), 12bit Deep |
|
Two Monitor: |
High Resolution Color, LCD Accord, 17 inch |
|
Image Processing: |
Edge enhancement, image strengthening, image lightening, |
|
Image Grey Level: |
4096 |
|
Image Max Resolution: |
1024 * 1280 pixel |
|
Image Processing: |
24bit for processing real time |
|
Image storage: |
Storage 60000 pictures in real time |
|
Zones & Zoom: |
1-9 Image regions, 2, 4, 8, 16 Times Enlarge, |
Installation environment:
|
Operation temperature/Humidity: |
0℃-45℃/20%-95%(non-condensing) |
|
Storage Temperature/Humidity: |
-20℃-60℃/20%-95%(non-condensing) |
|
Operation Power: |
220VAC(±10%)50±3Hz |
|
Power Consumption: |
1.8 KW (max), 0.3KW(working) |
|
Noise: |
<58db |
SECU SCAN Various products for your maket:
| Products Name | Model No. |
| X Ray Baggage Scanner | AT5030/AT6040/AT6550/AT8065/AT10080/AT100100 |
| Walk Through Metal Detector | AT-IIIA/AT-IIIC/AT-IIID/AT300A/AT300B/AT300C |
| Hand Held Metal Detector | AT2008/AT2009/MD300 |
| Under Vehicle Inspection System | AT3300/AT3000 |
| Bottle Liquid Scanner | AT1000/AT1500 |
| Explosive Trace Detector | HD600/HD300 |
SECU SCAN pays much attention to the package for the equipment.
We use the wooden case and moisture sealer which can insure the goods safety and humid
1.All of the products will be packed with wooden case and covered by packing film.
2.We offer considerate tranning program for engineers and operators and guarantee the after sell services
3.Enginners will be sent if there is any problem with the installation and commissioning.
4.We can do OEMs for x-ray baggage scanners/ walkthrough detectors/ handheld explosive detectors We can manufactur and sell
SECURITY ELECTRONIC EQUIPMENT CO.,LIMITED as the biggest manufacturer of security system and threats detection in south of China, have engaged in researching and developing new technology, producing, sales.
Container/Truck/Vehicle X-ray Scanner will be coming soon.
