High Penetration 40mm Baggage Screening Equipment For Security Inspection
Price:
Negotiable
MOQ:
1
Delivery Time:
7 days when we have stock,15 days when we have no stock
Brand:
SECUSCAN
Product Description
High Penetration 40mm Baggage Screening Equipment For Security Inspection
Advantages:
- We have 20000 square meter factory, 4 floor, 260 employess and 5 R&D team
- We have passed ISO9001, 16001, OHSMS18001, Health Inspection, SGS
- We got CE, USFDA certificate for our scanner
- We have full security product line which can meet your different needs
- We never stop researching and will have one or two new product each year
- We listen to our customer and solve their problems
Quick Details
X-ray Generator:
| Beam direction: | Diagonal |
| Generate angle: | 80 degree |
| Anode Voltage: | 140Kv |
| Anode power: | 0.35mA |
| Cooling / Duty Cycle: | Oil Cooling /100% |
General Specification:
| Tunnel Size: | 800(W)*650(H)mm |
| Conveyor Speed: | 0.22m/s |
| Conveyor Max Load: | 200kg |
| Wire Resolution: | 32AWG to 38AWG |
| Spatial resolution: | horizontal:1.3 or 1.0mm, vertical: 1.3 or 1.0mm |
| Penetration: | 40 to 43mm Steel |
| Film Safety: | Guarantee ISO1600 Film |
| X-ray Leakage: | <0.5 μSv/h (at a distance of 5cm from external housing) |
| Pass rate: | 720 bags per hour |
Installation Data:
| Operation temperature/Humidity: | 0℃-45℃/20%-95%(non-condensing) |
| Storage Temperature/Humidity: | -20℃-60℃/20%-95%(non-condensing) |
| Operation Power: | 220VAC(±10%)50±3Hz |
| Power Consumption: | 1.0 KW (max), 0.7KW(working) |
| Noise: | <58db |
Image System:
| X-ray Sensor: | L-Shaped Photodiode Array (multi-energetic) , 12bit Deep |
| Monitor: | High Resolution Color, LCD Accord, 19 inch |
| Image Processing: | Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning,image retrieval. |
| Image Grey Level: | 4096 |
| Image Processing: | 24bit for processing real time |
| Image storage: | Storage 60000 pictures in real time |
| Zoom: | max 16 Times Enlarge, Whole screen continuous observation |
Computer Specs:
- CPU: Intl Core 2 Duo 3400, 2.6GHz, 1MB, L2 Cache and 800Mhz FSB
- Motherboards: Intel G41/Nvidia chip set, 7025 or better on OEM motherboard
- Bus architecture: Integrated Graphics,5PCI, 1PCI Express *1 and 1PCI BX press *16
- Memory: 2GB 1333MHz DDR3 RAM, with Minimum2 total DIMM slots.
- Hard Disk drive: 500GB 7200 rpm serial ATA HDD.
- Mouse: Optical
Our service:
- Operation training program for end users
- Free of factory training for engineer from agents to end user
- Provide on-site trainning when customer requires
- If quality problems happen in guarantee period, our company will maintain for free.
- One year free spare parts and life time technical support
- After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
- If you are caught in some problems when using our products, welcome to contact us at any time.
