Big size X ray baggage scanner SPX10080 for Station/Hotel/Metro/Museum use x-ray scanner

General Specification :

Tunnel Size: 1000mm×800mm
Conveyor Speed: 0.22m/s
Conveyor height : 338.5mm
Conveyor Max Load:200kg


Penetration Resolution :30AWG guarantee, 32AWG typical
Film Safety :Guarantee ASA/ISO1600 Film
X-ray Leakage: <0.5 μSv/h (at a distance of 5cm From external housing)

Image System :

Technical Principle---------- Dual-energy X-ray Imaging;
X-ray Sensor---------- L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Monitor---------- High Resolution Color, LCD Accord, 17inch
Image Enhancement---------- 1-64times enlargement continuity, Color/BW, negative, high/low penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
Image Recall---------- All preceding images recallable, retrieval.
Explosives & Narcotics Detection: Explosives & narcotics alarm and highlight according to atomic number
signature
High Density Region Alarm---------- Impenetrable region alarm and highlight, for possible concealing of
threats and contrabands
Network Applications---------- Multiple remote applications available based on Ethernet LAN and windows platform, such as image centralized storage and identify, recheck workstation, and
network TIP, etc ( Optional) .
Images process---------- 24bit real time processing ,4colors analysis, Images displayed marked date and ID NO ,Count the number of bags ,Memory gray level:65536

X-ray Generator:

Other Characters:

Detect PCB board---------- UK brand Sensortech
Extension Rollers---------- customize size length
Support card reader operator access
CD DVR/RW unit---------- Optional
Computer system---------- XP system
Monitor---------- 17 inch DELL two monitors
