Hua Heng VS-3 High Sensitivity 40mV/mm/s Vibration Velocity Sensor with Explosion-proof ExiaIIBT5 and Wide Frequency Response 4-5000Hz
Price:
Negotiation
MOQ:
1
Delivery Time:
Negotiable
Brand:
Hua Heng
Product Description
Hua Heng VS-3 Vibration Velocity Sensor
High sensitivity industrial vibration monitoring solution for precise machinery condition assessment and predictive maintenance.
Key Specifications
Sensitivity: 40mV/mm/s ±5% (measured at 20℃, 60 Hz, and intensity of 10.0mm/s)
Amplitude limit: ≤2000μm (peak-to-peak)
Frequency response: 4～5000Hz
Maximum withstandable acceleration: 10g
Explosion-proof certification: ExiaIIBT5 (intrinsically safe)
Power supply: DC 24V; 3～8mA
Operating Environment
| Model | Temperature Range | Humidity |
|---|---|---|
| Standard VS-3 | -30℃～100℃ | ≤95% (non-condensing) |
| High Temperature VS-3H | -30℃～120℃ | ≤95% (non-condensing) |
Physical Characteristics
Measurement Direction: Vertical or Horizontal
Weight: 200g
Dimensions: Φ24mm×81mm (including waterproof connector)
Fixing Screw Holes: M10mm×1.5mm×8mm (deep) or M10mm×1mm×8mm (deep)
