VS-201 Integrated Vibration Temperature Sensor with 40mV/mm/s Sensitivity, PT100 Platinum Resistance, and 10～1000Hz Frequency Response for Machinery Health Monitoring
Price:
Negotiation
MOQ:
1
Delivery Time:
Negotiable
Brand:
OEM
Product Description
VS-201 Integrated Vibration Temperature Sensor
Advanced machinery health monitoring sensor combining vibration and temperature measurement capabilities for comprehensive equipment condition analysis.
Key Specifications
| Sensitivity | 40mV/mm/s ±5% (Measured at 20℃, 60 Hz, and intensity of 10.0mm/s) |
| Amplitude Limit | ≤2000μm (peak-to-peak) |
| Frequency Response | 10～1000Hz |
| Maximum Withstand Acceleration | 10g |
| Temperature Signal | PT100 platinum resistance thermometer |
| Operating Environment | Temperature -30℃～100℃, humidity ≤95% (non-condensing) |
| Measurement Direction | Vertical or horizontal |
Physical Dimensions
- Weight: 320g
- Dimensions: Φ32.5mm×210mm
- Probe length: 140mm
- Fixing screw hole: M20mm×1.5mm×15mm (depth)
![]()
