Portable Infrared Light Vein Finder Machine With Clear Image Skin Displayed
Portable Infrared Light Vein Locator Scanner With Clear Image Skin Dsplayed
With the gradual improvement of people's living standards, the rate of obesity also increases daily.
Since it is hard to locate and trace veins of the obesity and some infants, venipuncture has become an increasingly challenging field for medical practitioners and brings great pains to the patients during injection or blood-drawing. It is not surprising if a medical practitioner cannot find blood veins accurately. The rate of successful venipuncture for the first time is as law as 70%.To help medical personnel to locate blood veins easily, this Projection Vein Finder has been projected.
Product Applications
- Hospital, pediatric clinic, injection room
- Outpatient clinic, medical laboratory
- Blood bank, military medics unit, the CDC
- Rehabilitation center, nursing homes and others
Application Scope
- Children
- The elderly
- Obese patients
- Dark-skinned patients
- Patients with anemia, hypotension, or excessive loss of blood
Product Benefits
- Providing friendly treatment
- Reducing venipuncture failure and patients' pain
- Improving staff efficiency and patients' experience
- Attracting and helping to retain more patients
Product Advantage
| Portable and Flexible | Easy to move, fix and operate. One button for power on/off, one button for brightness, one button for color selection Total three Buttons for all operations. |
| Easy to learn, no need for complicated debugging and maintenance. | |
| 3 colors offered | White,grey and green vein for being selected according to user’s habit. |
| Safety | Using near infrared light, no laser, no radiation. |
| Accurate | Real show on skin, affectless images of veins. |
| Fast | Focus on vein automatically, show vein immediately. |
| Non-touch | Non-touch to anybody, prevent transmission of the virus. |
| Free environment | Effectively show the vein in dark or bright conditions, indoor and outdoor. Optional battery ensure 2 hours’ continuous working once external power supply is off. |
Product Specification
| Product model | BS5000 |
| Display mode | Projection |
| Source Type | near-infrared light (no radiation) |
| Infrared light wavelength | 850nm&940nm |
| Infrared radiation value | ≤0.6mW/m² |
| Alignment accuracy | ≤0.5mm |
| Image resolution | 856*480pixel |
| Brightness | 4 adjustable levels |
| Depth of detectio: | shallow: 0~2mm |
| deep: 2~4mm | |
| deeper: ≥4mm | |
| Optimal imaging distance | 210±30mm |
| Net weight | 430g |
| Dimension | 213mm*65mm*62mm(L x W x H) |
| Rated power | 8VA |
| Battery standby time | ≤2.5h |
| Charging time | ≤4h |
Product Images
