CE No Laser Infrared Vein Detector With Safe Light Source Vascular Projection Type
No Laser Infrared Vein Detector With Safe Light Source Vascular Projection Type
BS5000 is designed on the principle that hemoglobin has a stronger absorption under near-infrared light. After the photosensitive element acquires the infrared image of the skin, the product maps the outline of the vein through a series of digital image processing. Then, the projector projects the image on the surface of human skin to restore vein distribution. Vein Finder BS5000 is easy and simple to operate. Qualified medical personnel can easily locate for venipuncture by observing the vein image.
Product Specification
1. Product model : BS5000
2. Display mode: Projection
3. Source Type : near-infrared light (no radiation)
4. Wavelength: 850nm&940nm
5. Rradiation value: ≤0.6mW/m²
6. Alignment accuracy:≤0.5mm
7. Image resolution: 856*480pixel
8. Brightness: 4 adjustable levels
8. Depth of detectio: shallow: 0~2mm
deep: 2~4mm
deeper: ≥4mm
9. Optimal imaging distance: 210±30mm
10. Net weight: 430g
11. Dimension : 213mm*65mm*62mm(L x W x H)
12. Rated power: 8VA
13. Battery standby time ≤2.5h
14. Charging time: ≤4h
Product Feature
| Portable and Flexible | Easy to move, fix and operate. One button for power on/off, one button for brightness, one button for color selection Total three Buttons for all operations. |
| Easy to learn, no need for complicated debugging and maintenance. | |
| 3 colors offered | White,grey and green vein for being selected according to user’s habit. |
| Safety | Using near infrared light, no laser, no radiation. |
| Accurate | Real show on skin, affectless images of veins. |
| Fast | Focus on vein automatically, show vein immediately. |
| Non-touch | Non-touch to anybody, prevent transmission of the virus. |
| Free environment | Effectively show the vein in dark or bright conditions, indoor and outdoor. Optional battery ensure 2 hours’ continuous working once external power supply is off. |
| Product Benefits | Providing friendly treatment |
| Reducing venipuncture failure and patients' pain | |
| Improving staff efficiency and patients' experience | |
| Attracting and helping to retain more patients | |
| Product Applications | Hospital, pediatric clinic, injection room |
| Outpatient clinic, medical laboratory | |
| Blood bank, military medics unit, the CDC | |
| Rehabilitation center, nursing homes and others | |
| Application Scope | Children |
| The elderly | |
| Obese patients | |
| Dark-skinned patients | |
| Patients with anemia, hypotension, or excessive loss of blood |
