APP Free 10MHz 20-305mm Color Doppler Ultrasound Scanner
Features
- Both USB and Wifi
- Exceptional image quality with Ipad/Android /windows display
- Durable design-can be extended to two years warranty
- Save and view images as needed
- Software upgrades via iPad/iPhone APP store
- OEM/ODM
Both USB and WIFI Wireless Ultrasound Technical Specifications
|
Picture |
U3 Convex U3 Linear |
| Type | Convex / Linear |
| Frequency | Convex:3.5/5.0MHz; Linear:7.5/10MHz |
| Depth | Convex:90~305mm; Linear:20~100mm |
| Elements | 128 |
| Radius | Convex: R60 |
| Length | Linear: 46mm |
| Dimensions |
Convex: 115(h)x70(w)x20(d)mm Linear: 115(h)x60(w)x20(d) mm |
| Package size | 240(h)x235(w)x100(d) mm |
| Net weight | Convex: 125g Linear:102g |
| Gross weight | 1KGS |
| Wifi type | 802.11n/20MHz/5G |
| APP interface | GN(gain) 30-105 |
| Adjustment |
D(depth) ENH(enhancement) 0-4 DR(dynamic range) 40-110 F(frequency) 3.5-10MHz
B, B+M ,B+Color ,B+PW ,B+PDI
B:Length,Area,Circumference,GA (CRL,BPD,GS,FL,HC,AC) B+M: Heart Rate, Time, Distance B+PW:Velocity, Heart Rate(2), S/D, Depth |
| Battery Life | 5~8 years |
| Voltage | 3.8v |
| Replaceable | Yes |
| Capacity | 1350mAh |
| Standby | 1~4h |
| Bootup | Platform dependent, generally <5 seconds |
| Application |
Obstetrics / Gynecology;Lung;Kidney;Urology
Vascular;Pediatrics;Carotid;Small Parts |
| Software | Android/ Windows / IOS ,Download for free |
| Model | U3 Convex | U3 Linear |
| Photo |  |
 |
| Type | Convex | Linear |
| Frequency | 3.5-5MHz | 7.5-10MHz |
| Depth | 90-305mm | 20-100mm |
| Elements | 128 | 128 |
| Radius | R60 | N/A |
| Length | N/A | 46mm |
| Display mode | B, BM, THI, Color, Power, PW | B, BM, THI, Color, Power, PW |
| APP interface adjustment |
GN(gain) D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Annote, Page Left/Right Up/Down 8TGC |
GN(gain) D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Biopsy Annote, Page Left/Right Up/Down 8TGC |
| Measurement |
B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL)
B+M: Heart Rate, Time, Distance
B+PW: Velocity, Heart Rate (2), S/D, Depth |
B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL)
B+M: Heart Rate, Time, Distance
B+PW: Velocity, Heart Rate (2), S/D, Depth |
| Dimensions | 115(h)*70(w)*20(d)mm | 115(h)*60(w)*20(d)mm |
| Package size | 185(h)*105(w)*55(d)mm | 185(h)*105(w)*55(d)mm |
| Net weight | 120g | 102g |
| Gross weight | 1kg | 1kg |
| Wifi type | 802.11g/20MHz/5G | 802.11g/20MHz/5G |
| Connection type | WiFi & USB | WiFi & USB |
| Supporting Device | Tablet, Smart phone, PC, etc. | Tablet, Smart phone, PC, etc. |
| Working system | Android, iOS, Windows | Android, iOS, Windows |
| Application |
Abdominal Emergency Cardiac Obstetrics / Gynecology Lung Kidney Urology |
Breast Thyroid MSK Superficial Vascular Pediatrics Carotid Small Parts |
| Language |
Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil) |
Chinese,English,Russian,Italian, Spanish,Portuguese(Brazil) |
| Battery life | 5-8 years | 5-8 years |
| Voltage | 3.8v | 3.8v |
| Replaceable | Yes | Yes |
| Capacity | 1350mAh | 1350mAh |
| Standby | 12h | 12h |
| Bootup |
Platform dependent, generally <5 seconds |
Platform dependent, generally <5 seconds |
Standard Configuration
| 1 | Wireless probe | 1pc |
| 2 | USB cable | 1pc |
| 3 | Power Plug | 1pc |
| 4 | Wireless charger | 1pc |
| 5 | Wrist strap | 1pc |
| 6 | Portable aluminium alloy box | 1pc |
| 7 | User's Manual_E format | 1pc |
| 8 | Warranty Card_Eformat | 1pc |
