Full Automatic 5 Gallon Water Filling Machine , Mineral Pure Water Production Line

Price Negotiable
Price: Negotiable
MOQ: 1 set
Delivery Time: 30 days
Brand: Sunswell
Product Description



Full Automatic 5 Gallon / 20 L Barrel Mineral Pure Water Production Line / Filling machine





Description:

This 5 gallons jar water filling machine specially produces 5 gallons and 3 gallons jar drinking water.
In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer, washing solution can be used circularly.
The sealer can seal barrel caps automatically. The line equips with water spraying device to sterilize capes of bottles in order to ensure those caps are aseptic and healthy, also this line can automatically carry out barrel feeding, washing, sterilizing, filling, capping, counting and products discharging.




Applications:

Still water, pure water, RO water, mineral water, sparkling water, etc. in 3 gallon, 4 gallon and 5 gallon bottles.



Technical features of 5 gallon water filling machine

  • The machine integrates rinser, filler and capper together.
  • The machine is of stainless steel, resisting corrosion and easy to clean.
  • The main electrical components and gas circuit elements are all of international brand.


Equipment structure of 5 gallon water filling machine

  • Automatic bottle loader
  • Barrel rinser
  • Filler
  • Capper
  • According to the customer’s requirement, the machine could be equipped with automatic cap separator, automatic leakage inspector, barrel washer, automatic cap loader, shrink wrapper, etc.



Specifications:



Model

TGX-1200

Product capacity

1200 barrel/hour

Filling head

12

Equipment size

2200×2100×2200mm (filler)

 1000×1200×2200mm (capper)

Power supply

Main machine (KW)

13

Compressed air

Air pressure

0.5Mpa

Gas consumption

1.5m3/min

Washing working position

circulating water (2 positions)

pure water (2 positions)

Drip working position: 1 pc

consumption

4T/hr
