Fuel Oil Centrifuge Disc Stack Centrifuges , 2000LPH 3 Phase Separator


Description

Model PDSD2000 separator is mainly used to remove water and mechanical impurities from diesel oil, lubricating oil and other mineral oil in marine diesel engine unit and landused diesel generator unit of power station so as to reduce wear of the diesel engine and other machine, and prolong engine life.

The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.

The machine adopts automatic control, and has the advantages of high efficiency, low oil consumption, convenient operation and economic maintenance cost.

The clear oil and dirty water are pumped out by centripetal pump, the sludge is discharged automatically and fully.

The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for long time with low vibration, safety and security.

The design, product and acceptance are conformed to the standard of GB/T5745 “Marine Disc Separator”.

Main Technical Specification

The whole unit consists of

1. Separator  2. Oil feed pump  3. Electric control box  4. Steam heater  5. Temperature adjusting valve  6. Steam trap  7. Safety valve  8. Pressure switch  9. Oil filter  10. Pressure gauge  11. Vacuum gauge  12. Temperature sensor  13. 2/2 Solenoid valve 14. 2/3 Solenoid valve  15. Air reduction pressure valve  16. Pneumatic three-way valve  17. Stop-check valve 18. Brass filter ball valve  19. Water pressure reducing valve  20. Ball valve  21. Skid

Automatic Control System



Condition for mineral oil separation and actual capacity (refer to the chart)

Overview
