Steel Angle / L Profile Cold Roll Forming Machine With Manual Decoiler

   A). Main Specification

Material: GI or Carbon steel

Material thickness: 1.0-2.0mm or 2.0-4.0mm ( depend on custome’s requirement )

Main power: 4KW

Forming station: 8-11 stations

Weight of machine: about 4 Ton

Decoiler: manual decoiler

Weight capacity of decoiler: 3 Ton

Drive: Chain transmission

Machine post thickness: S18

Cutting: Hydraulic cutting

Hydraulic power: 3KW

Cutting tolence: +/-2mm

Electrical Control: PLC Frequency Control System with touch screen

PLC: PANASONIC Brand

Encoder: OMRON Brand

Transducer: PANASONIC Brand

   B). Main Components

Decoiler ----------------------------------------------- 1 Unit

Feeding & Leveling --------------------------------- 1 Unit

Main roll forming machine ------------------------ 1 Unit

Hydraulic cutting device --------------------------- 1 Unit

Hydraulic Station ------------------------------------- 1 Unit

PLC computer control ------------------------------ 1 Unit

Output table ------------------------------------------- 1 Unit

   C). Working Flow

Decoiler --- Fedding & Leveling --- Roll Forming --- Cut-to-length --- Run out table

   D). Applications

Metal angle, Steel angle, Angle steel, l section, Wall angle, l shape, l profile

   E ). Competitive Advantages

1 Year Warranty

High Quality

Reasonable Price

Good after Service

More Than 10 Years Experience

   F). Other Machine Pictures
