PLC Touch Screen Control Carbon Steel Roll Forming Machines For 1.5 - 3.0mm Thickness
PLC Touch Screen Control Carbon Steel C Purlin Roll Forming Machine For Thickness 1.5-3.0mm
Main Specification
| Material |
GI, Carbon steel |
|
Material thickness |
1.5-3.0mm |
|
Machine diameter |
about 11500x1500x1300mm ( LXWXH ) |
|
Decoiler |
Manual or hydraulic decoiler ( customer can choose ) |
|
Weight capacity of decoiler |
5 Ton |
|
Forming station |
14 |
|
Principle axis |
75mm diameter |
|
Forming speed |
0-15m/min |
- Drive type: 1.5' chain transmission
- Roller material: GCr15 steel, quenched and heated process
- Main power: 15KW
- Hydraulic power: 11KW
- Punching: hydraulic punching
- Electrical Control: PLC Frequency Control System with touch screen
- PLC: PANASONIC Brand
- Encoder: OMRON Brand
- Transducer: PANASONIC Brand
Main Components
| Decoiler / Uncoiler | 1 Unit |
| Feeding Guide & Leveling Device | 1 Unit |
| Roll Forming Machine | 1 Unit |
| Hydraulic Punching | 1 Unit |
| Hydraulic Cutting System | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control Box | 1 Unit |
| Support Tables | 1 Unit |
Work Flowing
Decoiler --- Fedding & Leveling --- Roll Forming --- Punching --- Cut-to-length --- Run out table
Profile Drawing
Application
C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure
Advantages
- High Quality
- Reliable
- Durable
- Reasonable Price
- Good after Service
- 1 Year Warranty
- More Than 10 Years Experience
Machine Pictures
