Simple Steel Coil Slitting Cutting Machine for Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

Simple Steel Coil Slitting Cutting Machine for Slitting Carbon steel / GI / Color Steel Q235-Q350 Coil into Strips

   A). Introduction

1. This line includes Uncoiler, Feeding Guide, Slitting Machine, Cantilevering Separating, Tension Control Board, Console and General electrical equipment.
2. Electrical Source: 380V/50Hz/3Ph ( or depend on local requirement )
3. Speed of line: 0-40m/min.
4. Main power: 48 KW
5. Floor Area accupied by machine: 10m (L) x 3m ( Width )
6. Production operation: 1 Skilled Worker, 1 common worker

   B).  Main Components

1. Hydraulic Decoiler -------------------------------------------------- 1 Unit
2. Leveling and Feeding Guide ------------------------------------- 1 Unit
3. Slitting Machine ----------------------------------------------------- 1 Unit
4. Cantilevering Separating ------------------------------------------ 1 Unit
5. Tension Control Board --------------------------------------------- 1 Unit
6. Console --------------------------------------------------------------- 1 Unit
7. General electrical equipment ------------------------------------- 1 Unit

   C). Main Specification

1. Material: Carbon steel, GI, Color steel – Q235-Q350
2. Thickness: 0.2-2.0mm
3. Width: 400-1300mm
4. Inner diameter of coil: φ450—φ510
5. Outer diameter of coil: φ1500mm. Max.
6. Weight of coil: 5 Ton. Max.
7. Diameter of slitting blades: φ120
8. Material of slitting blades: 40Cr

   D). Finished Products Data

1. Tolerance of width: ≤±0.02mm
2. Max. strips to be slited: 10 pieces
3. Min. width of the pieces: 50mm

   E). Applications

   F). Competitive Advantages

• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience
• Professional Team Support

   G). Reference Pictures
