B Type 3 Rows DIN 41612 Connector 48P Eurocard Straight Female Receptacle
B Type 3 rows Receptacle DIN 41612 connector 48P Eurocard Straight Female Connector
Detail Description
Product Category: Eurocard Connector
Product Line: DIN 41612 Connector
Connector Version: B Type
Type: Straight PCB Connector
Number of Terminal: 2 rows * 32P = 64P
Connector Style:Receptacle
Gender: Female
Insulator Color: Grey
Insulator Material: PBT
Contact pin Material: Phosphor Bronze
Terminals Type: Vertical
Application: PCB Board
Technology Parameters
| Material: | |
| Insulator: | Glass-filled thermoplastic PBT |
| Contacts: | Brass/Phosphor Bronze. |
| Plating: | full gold or selected gold in mating area |
| 100u''min.tin-lead on termination area | |
| with entire contact under-plated 50u''min.Nicket. | |
| Electrical: | |
| Contact Resistance: | 30 milliohms Max at 1 AMP DC. |
| Insulator Resistance: | 1000 magohms at 500 VDC. |
| Dielectric Withstanding Voltage: | 1000VAC/rms 60 Hz For 1 miniute. |
| Current Rating: | 2 AMP. |
| Voltage Rating: | 250 VAC/rms 60 Hz. |
DIN 41612 is a DIN standard for electrical connectors, widely used in rack-based electrical systems. Standardization of connectors is a prerequisite for open systems, where users expect components from different suppliers to function together. The most widely known use of DIN 41612 connectors is in the VMEbus and NuBus systems. This standard has been withdrawn and replaced by the international standards IEC 60603-2 and EN 60603-2.
DIN 41612 connectors are used on Pancon STEbus, Futurebus, VMEbus, Multibus II, NuBus, VXI Bus, eurocard TRAM main boards and Europe Card Bus, all of which typically use the male DIN 41612 connector on the Eurocards to plug into the female DIN on the backplane 41612 A 19" rack chassis.
