TE 229974-1 Replacement Connector, 50 / 64 Position D-Shaped Connector, Plug, Cable-to-Cable, Cable Mount (Free-Hanging), 2.16 mm [.085 in] Centerline, CHAMP Docking Connectors
Price:
Negotiable
MOQ:
10pcs
Delivery Time:
7-10 days
Brand:
FUYCONN
Product Description
TE 229974-1 Replacement Connector
Product Overview
50/64 Position D-Shaped Connector, Plug, Cable-to-Cable, Cable Mount (Free-Hanging), 2.16 mm [.085 in] Centerline, CHAMP Docking Connectors
IDC D-sub CHAMP docking connector plug assembly, intended for cable to cable applications with Insulation Displacement Crimp (IDC) mass termination. Has a centerline pitch of 2.16 mm and used for signal circuit application.
Key Features
- Number of Positions: 50 | 64
- Connector & Housing Type: Plug
- Connector System: Cable-to-Cable
- Connector Mounting Type: Cable Mount (Free-Hanging)
- Centerline (Pitch): 2.16 mm [.085 in]
Technical Specifications
| Category | Specifications |
|---|---|
| Product Type | Connector & Housing Type: Plug Connector System: Cable-to-Cable Connector Product Type: Connector Assembly Connector & Contact Terminates To: Wire & Cable |
| Configuration | Number of Positions: 50 | 64 Number of Rows: 2 Compatible With: Discrete Wire | Ribbon Cable | Round Jacketed Cable |
| Body Features | Primary Product Color: Black Ribbon Cable Centerline Spacing: 1.27 mm [.05 in] Cover Material: Thermoplastic Connector Profile: Low | Standard |
| Contact Features | Contact Mating Area Plating: Gold (Au) | Gold Flash Contact Base Material: Copper Alloy | Phosphor Bronze Contact Current Rating: 5 A Contact Options: Installed |
| Termination | Termination Method: Insulation Displacement (IDC) |
| Mechanical Attachment | Mating Retention Type: Screwlocks Thread Size: 4-40 UNC 2B | M3 Connector Mounting Type: Cable Mount (Free-Hanging) |
| Dimensions | Wire Size (AWG): 24 | 26 | 26-24 | 28 Operating Temperature: -55°C to 105°C |
| Application | Shielded: No Circuit Application: Signal |
