SMT Connector, 14 Pin Centronic Male Clip Connectors For 1.6mm PCB Board Certificated UL
SMT Connector, 14 Pin Centronic Male Clip Connectors For 1.6mm PCB Board Certificated UL
Detail Description:
Product Category: Centronic connector
Product Line: Champ Connector
Type: Centronic SMT Type Connector
Number of Terminal: 14 pin
Connector Style:Plug
Gender: Male
Insulator Color: Black or Blue
Insulator Material: PBT
Contact pin Material: Phosphor Bronze
Shield Plating: Nickel
Mounting Option: Clip PCB Board, MD Type
Application: 1.6mm thickness PCB Board
Advantage:
1,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample available in 2 days
14 Pin Centronic Male SMT Clip Connectors For 1.6mm PCB Board Certificated UL
Product features
| 1. Product Line: | Centronic Connector |
| 2. Connector Gender: | Male |
| 4. Number of Position: | 14pin 24pin 36pin 50pin |
| 5. Contact Material: Copper Alloy | Copper Alloy / Phosphore Bronze |
| 6. Contact Plating: | 1U", 3U", 5U", 10U", 15U",30U" |
| 7. Comb Material: | Thermoplastic |
| 8. UL Flammability Rating: UL-94-V0 | UL-94-V0 |
Electrical Specifications
| 1. Current Rating: | 5Amp |
| 2. Voltage rating: | DC 1000v per minute |
| 3. Insulator Resistance: | 1000Mn MIN.(at 500V DC) |
| 4. Operation Temperature: | -55°C to +105°C |
