TYCO 64 Pin Male Centronic Champ IDC Connectors with 45 degree Metal Cover Certificated UL
Price:
USD2 - USD5
MOQ:
10pcs
Delivery Time:
7-10 days
Brand:
FUYCONN
Product Description
TYCO 64Pin Male Centronic Champ Connectors 32 Pairs IDC Type with Metal Cover Certificated UL
Detail Description
Product Category: Centronic connector
Product Line: Champ Connector
Type: Centronic IDC Connector
Connector Style:Plug
Number of Terminal: 64 pin
Gender: Male
Insulator Color: Black
Insulator Material: PBT
Contact pin Material: Phosphor Bronze
Shield Plating: Nickel
Centerline = 2.16mm [0.085in]
Mounting Option: 45°Cable Outlet
Cover: Metal Cover
Application: Communication Equipment
Technology Parameters
Electrical Specifications
| 1. Current Rating: | 5Amp |
| 2. Voltage rating: | DC 1000v per minute |
| 3. Insulator Resistance: | 1000Mn MIN.(at 500V DC) |
| 4. Operation Temperature: | -55°C to +105°C |
Product features
| 1. Product Line: | Centronic Connector |
| 2. Connector Gender: | Male |
| 4. Number of Position: | 64 pin |
| 5. Contact Material: Copper Alloy | Phosphore Bronze |
| 6. Contact Plating: | 1U", 3U", 5U", 10U", 15U",30U" |
| 7. Comb Material: | Thermoplastic |
| 8. UL Flammability Rating: UL-94-V0 | UL-94-V0 |
| 9. Housing |
45 degree metal Housing |
