ASME SB111 UNS C71500 Copper Nickel Tube , Sea Water CuNi 70/30 Seamless Tube
ASTM B111 / ASME SB111 C71500 CuNi30Mn1Fe Copper Nickel Alloy Seamless Tube
Copper-nickel alloys, such as C71500 (high levels of copper (70-73%) and nickel (29-31%). It also contains small amounts of other elements like iron and manganese.), are known for their excellent resistance to corrosion, especially in marine environments with exposure to seawater. B111 C71500 tubes find applications in industries such as marine engineering, oil and gas, power generation, chemical processing, and HVAC systems where corrosion resistance and thermal conductivity are critical factors.
ASME SB111 UNS C71500 Copper Nickel Tube Equivalent Material
| Material Designation | Corresponding Material Symbol | ||||
| GB/T8890 | ASTM B111 | BS2871 | JIS H3300 | DIN1785 | |
| Copper-Nickel | BFe30-1-1 | C71500 | CN107 | C7150 | CuNi30Mn1Fe |
ASME SB111 UNS C71500 Copper Nickel Tube Physical Properties
| Properties | Metric | Imperial |
| Density | 8.94 g/cm3 | 0.323 lb/in3 |
| Melting point | 1171°C | 2140°F |
ASME SB111 UNS C71500 Copper Nickel Tube Chemical Composition
| Grade | C(Max) | Pb | Mn | P | S | Zn | Fe | Ni | Cu |
| C71500 | 0.05 | 0.02 | 1.0 | 0.02 | 0.02 | 0.50 | 0.4-1.0 | 29.0-33.0 | Balance |
ASME SB111 UNS C71500 Copper Nickel Tube Mechanical Properties
| Properties | Metric | Imperial |
| Tensile strength, ultimate | 372-517 MPa | 54000-75000 psi |
| Tensile strength, yield (depending on temper) | 88.0-483 MPa | 12800-70100 psi |
| Elongation at break (in 381 mm) | 45.0% | 45.0% |
| Charpy impact | 107 J | 78.9 ft-lb |
| Machinability (UNS C36000 (free-cutting brass) = 100%) | 20% | 20% |
| Shear modulus | 57.0 GPa | 8270 ksi |
| Poisson's ratio | 0.34 | 0.34 |
| Elastic modulus | 150 GPa | 21800 ksi |
| Material Designation | Corresponding Material Symbol | ||||
| GB/T8890 | ASTM B111 | BS2871 | JIS H3300 | DIN 1785 | |
| Copper-Nickel | BFe10-1-1 | C70600 Pipe | CN102 | C7060 | CuNi10Fe1Mn |
| BFe30-1-1 | C71500 Pipe | CN107 | C7150 | CuNi30Mn1Fe | |
| (BFe30-2-2) | C71640 | CN108 | C7164 | CuNi30Fe2Mn2 | |
| (BFe5-1.5-0.5) | C70400 | – | – | – | |
| B7 | – | – | – | – | |
| Aluminium Brass | HAL77-2 | C68700 Tube | CZ110 | C6870 | CuZn20Al2 |
| Admiralty Brass | HSn70-1 | C44300 Tube | CZ111 | C4430 | CuZn28Sn1 |
| Boric Brass | Hsn70-18 | – | – | – | – |
| HSn70-1 AB | – | – | – | – | |
| Arsenical Brass | H68A | – | CZ126 | – | – |
| Brass Tubes | H65/H63 | C28000/C27200 | CZ108 | C2800/C2700 | CuZn36/CuZn37 |
Applications
- Hydraulic lines
- Fish cages for aquaculture
- Heat exchangers and condensers
- Desalination units
- Sea water pipework
- Tubes for power plants and ships
- Offshore fire water systems
- Pumps, valves, sheathing and fittings for ship hulls
- Desalination units
- Hydraulic lines
- Fish cages for aquaculture
- Heat exchangers and condensers
- Sea water pipework
- Offshore fire water systems
- Tubes for power plants and ships
- Pumps, valves, sheathing and fittings for ship hulls
