Inconel 600 (Alloy 600, UNS N06600) Nickel Alloy Flange, ASTM B564 / ASME SA564, Weld-neck raised face (WNRF)
Inconel 600 (Alloy 600, UNS N06600) Nickel Alloy Flange, ASTM B564 / ASME SA564, Weld-neck raised face (WNRF)
What is Inconel 600 Nickel Alloy Flange?
Inconel 600 Nickel Alloy Flange is a high-performance industrial flange made from Inconel 600 (UNS N06600), a nickel-chromium-iron alloy. It is known for excellent resistance to heat, corrosion, and oxidation, making it ideal for harsh environments like chemical processing, power generation, and marine applications. These flanges maintain strength and stability in high-temperature and corrosive conditions.
When to Choose Inconel 600 Over Other Materials
|
Use Case |
Why Inconel 600? |
|---|---|
|
High-temperature service |
Withstands heat better than most stainless steels |
|
Corrosive chemical environments |
Superior resistance to acids and chlorides |
|
Thermal cycling |
Excellent fatigue resistance and dimensional stability |
|
Nuclear/energy sectors |
Good radiation resistance and low corrosion under neutron flux |
Chemical Composition of ASTM B564 UNS N06600 (%)
|
Nickel |
≥72.0 |
|
Chromium |
14.0-17.0 |
|
Iron |
6.00-10.00 |
|
Copper |
≤0.50 |
|
Carbon |
≤0.15 |
|
Sulfur |
≤0.015 |
|
Silicon |
≤0.50 |
|
Manganese |
≤1.00 |
Physical Properties of ASTM B564 UNS N06600
|
Density |
Melting Range |
Specific Heat |
Curie Temperature |
Electrical Resistivity |
|||||
|
lb/in3 |
Mg/m3 |
°F |
°C |
Btu/lb-°F |
J/kg-°C |
°F |
°C |
mil/ft |
μΩ-m |
|
0.306 |
8.47 |
2470-2575 |
1354-1413 |
0.106 |
444.00 |
-192 |
-124 |
620 |
1.03 |
Mechanical Properties of ASTM B564 UNS N06600 Alloy 600 Flange
|
Density |
8.47 g/cm3 |
|
Melting Point |
1413 °C (2580 °F) |
|
Elongation |
40 % |
|
Tensile Strength |
Psi – 95,000 , MPa – 655 |
|
Yield Strength (0.2%Offset) |
Psi – 45,000 , MPa – 310 |
UNS N06600 / Inconel 600 Flange – Material Equivalents
|
Standard |
Equivalent Grade |
|---|---|
|
UNS |
N06600 |
|
ASTM |
B564 (for flanges), B166, B167, B168 |
|
ASME |
SB564 (identical to ASTM B564) |
|
DIN / EN |
2.4816 |
|
ISO |
NiCr15Fe (similar composition) |
|
BS (British) |
NA 14 |
|
JIS (Japan) |
NCF 600 |
Characteristic of ASTM B564 UNS N06600 Alloy 600 Flange
- Excellent High-Temperature Strength
- Outstanding Corrosion Resistance
- Good Resistance to Stress Corrosion Cracking (SCC)
- Excellent Formability and Weldability
- Oxidation Resistance
Application
- Chemical and Petrochemical Processing
- Nuclear Power Plants
- Heat Treatment and Furnace Components
- Aerospace and Jet Engine Components
- Food Processing Equipment
- Marine and Offshore Applications
- Pulp and Paper Industry
