ASTM A179 SLMS Cold Drawn Low Carbon Steel Heat Exchanger Tubes
ASTM A179 SLMS Cold Drawn Low Carbon Steel Heat Exchanger Tubes
ASTM A179 covers minimum-wall thickness, seamless cold-drawn low-carbon steel tubes for tubular, heat exchanger, condensers, and other heat transfer services. seamless ASTM A 179 steel tube is supplied and produced by cold drawning method. Chemical composition contains carbon, manganese, phosphorus, and sulfur.
Specifications
| Dimensions | All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API. | ||||
| Sizes | O.D.: 6.0~114.0; W.T.: 1~15; L: max 12000 | ||||
| Diameter | 0.35mm to 6.35mm OD in thickness ranging from 0.1mm to 1.2mm | ||||
| Schedule | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules | ||||
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. | ||||
| Length | 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; and so on. Max length: 27000mm, also U bending can be offered. | ||||
| Wall Thickness | SCH10, SCH20, SCH30, STD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS DIN, JIS standard thickness | ||||
Test Required
Hardness test, Flattening test, Flaring test, Flange test, Hydrostatic test,etc
Chemical Composition
| Chemical Composition | C | Mn | P≤ | S≤ | Si≤ |
| 0.06-0.18 | 0.27-0.63 | 0.035 | 0.035 | 0.25 |
Mechanical Property
| Steel Grade | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation (%) |
| ASTM A179 | ≥180 | ≥325 | ≥35 |
Applications Industry
Pharmaceutical Equipment
Off-Shore Oil Drilling Companies
Chemical Equipment
Power Generation
Sea Water Equipment
Petrochemicals
Heat Exchangers
Gas Processing
Condensers
Pharmaceuticals
Specialty Chemicals
Pulp and Paper Industry
