Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Abstract of Nickel 200 Seamless Tube
Nickel 200 tubes are made of 99% nickel alloy, known as commercial pure nickel. The material has a minimum yield strength of 148MPa and a minimum tensile strength of 462MPa, but the material has very high corrosion resistance. The material consists of carbon, manganese, silicon, sulfur, copper, iron and 99% nickel.
Applications where these ASTM B163 nickel 200 tubes can be used include chemical storage and processing, synthetic fiber production, and methods using fluorine and sodium hydroxide. However, beyond food processing, other applications include defence and aerospace. At the same time, these ASTM B163 tubes have excellent alkali resistance at different concentrations and temperatures.
Key Features of Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube
-
Material: Nickel Alloy 200 (UNS N02200)
-
Form: Seamless tube (no welds, uniform wall thickness)
-
Nickel Content: ≥ 99.6%
-
Standards: ASTM B161 (general service), ASTM B163 (condenser/heat exchanger applications
ASTM B163 N02200 Tube Chemical Composition
| Cu | Ni | Fe | Mn | C | S | Si |
| 0.25 max | 99.0 min | 0.4 max | 0.35 max | 0.15 max | 0.01 max | 0.1 max |
ASTM B163 N02200 Tube Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –790 | Psi – 52,000 , MPa – 355 | 40 % |
Nickel 200 / UNS N02200 Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN | BS | GOST | AFNOR |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | Ni 99.2 | NA 11 | НП-2 | N-100M |
ASTM B163 N02200 Tube Physical Properties
| Grade | ASTM B163 Nickel 200 | |
|---|---|---|
| Density | 8.9 g/cm3 | |
| Melting Point | 1446 °C (2635 °F) | |
Application of Nickel 200 Tube
-
Caustic soda production
-
Food processing (especially with caustics)
-
Chemical processing
-
Heat exchangers and condensers
-
Aerospace components
-
Marine and offshore systems
-
Electronics (battery and electrode connections)
