ASTM A249 TP304L, UNS S30403 Stainless Steel Welded Tube For Heat Exchangers Boilers
ASTM A249 TP304L, UNS S30403 Stainless Steel Welded Tube For Heat Exchangers Boilers
ASTM A249 TP304L is a low carbon austenitic grade of stainless steel. The lower carbon content makes it easy welded and reduces corrosion. SS304L tube is tougher and has high wear and tear properties. The ASTM A249 TP304L welded tube has many advantageous properties, like its good formability and good weldable properties and so on. SS 304L welded Tube is widely used in heat exchangers, boilers, condensers, power generation and oil and gas plants.
Specifications:
| Specification | ASTM A249 Tp304L / ASME SA249 Tp304L Tube |
| Shapes | Round, Rectangular, U Shape, Square, Straight, Coiled, Etc. |
| Technique | Cold rolled, Cold drawn, Hot rolled |
| Type | Welded |
| Thickness | SCH 5 To SCH XXS |
| End | Beveled End, Treaded, Plain End |
| Processing Service | Bending, Moulding, Welding, Cutting, Decoiling, Punching |
| Standard | JIS, DIN, ASTM, GB, AISI, EN, SUS |
| Delivery Condition | Cold Drawn, Annealed and Pickled (AP), Polished, MF, Bright Annealed (BA) |
Equivalent Grades:
| STANDARD | UNS | WERKSTOFF NR. | EN | AFNOR | JIS | BS | GOST |
| SS304L | S30403 | 1.4306/1.4307 | X2CrNi18-9 / X2CrNi19-11 | Z3CN18‐10 | SUS 304L | 304S11 | 03Х18Н11 |
Chemical Composition:
| Grade | C | Ni | Si | N | S | Mn | P | Cr | |
| SS 304L | min. | - | 8 | - | - | - | - | - | 18 |
| max. | 0.03 | 12 | 0.75 | 0.1 | 0.03 | 2 | 0.045 | 20 | |
Mechanical Properties:
| Tensile Strength, min | Yield Strength 0.2% Proof, min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
| 485 MPa | 170 MPa | 40 % | 92 | 201 |
Applications:
Chemical Industries
Petrochemical Industries
Gas Processing Equipments
Food Processing Equipments
Fertilizers Industries
Sugar Industries
Oil & Gas Industries
Shipbuilding Equipments
Nuclear Power
