Water Treatment, ASTM A182 F904L, N08904 Stainless Steel Slip On Flange, Raised Face, B16.5
Water Treatment, ASTM A182 F904L, N08904 Stainless Steel Slip On Flange, Raised Face, B16.5
ASTM A182 F904L Stainless steel Slip On Raised Face Flange is combination of nickel content of the steel material, with a 25 % nickel content. Stainless Steel 904L Flange is a good alternative to most conventional stainless steels. F904L Stainless Steel Pipe flange has good resistance and can be easily welded. ASTM A182 F904L SS Flange's working temperatures is 1562°F - 2102°F(850°C - 1150°C).
ASTM A182 UNS N08904 Stainless Steel Slip On Flanges is used in many industries to allow fluid flow through pipes without interruptions by connecting them with such Flanges. ASTM A182 F904L Stainless Steel Slip On Flanges have excellent resistant to corrosion and oxidation. They also have high weldability and strength. These Slip On Flanges serve better in environments having sulphuric acids.
Specification:
| Specifications | ASTM A182, ASME SA182 |
| Size Range | 1/8” to 48” |
| Standards | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges, ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN |
| Main Types | Forged / Threaded / Screwed / Plate |
| Types of Flanges |
Blind Ring Flange (BLRF) Lap Joint Ring Flange (LJRF) Socket Weld Ring Flange (SWRF) Threaded Ring Flange Weld Neck Ring Flange (WNRF) Slip-On Ring Flange (SORF) Ring Type Joint Flange (RTJF) |
| Pressure Ratings | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, Etc. |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Ring Type Joint (RTJ), Flat Face (FF), Lap-Joint Face (LJF), Raised Face (RF), Large Male-Female (LMF), Small Male-Female (SMF), Large Tongue & Groove, Small Tongue, Groove |
Equivalent Grades:
| STANDARD | UNS | WERKSTOFF NR. | KS | JIS | BS | AFNOR | EN |
| SS904L | N08904 | 1.4539 | STS 317J5L | SUS 904L | 904S13 | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Chemical Properties:
| Grade | % | C | Ni | Si | MO | P | S | Mn | Cr | Cu |
| SS F904L | Min | - | 23.00 | - | 4.00 | - | - | - | 19.0 | 1.00 |
| max | 0.20 | 28.00 | 1.00 | 5.00 | 0.045 | 0.035 | 2.00 | 23.0 | 2.00 |
Mechanical Properties:
| Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Density | Elongation |
| 32000 Psi, 220 Mpa | 1350 °C (2460 °F) | 71000 Psi, 490 Mpa | 7.95 g/cm3 | 35 % |
Applications:
Chemical Industries
Metallurgical Industries
Marine Equipments
Oil and Gas Plants
Plastics Industries
Petrochemical Industries
Pollution Control Equipments
Paper Making Plants
Metalworking Industries
Power Generation Industries
Fertilizers Industries
Food Processing Industries
