ASTM A213 Grade T5 Alloy Steel Seamless Tube Heat Exchanger Tube
ASTM A213 Alloy T5 Alloy Steel Seamless Tube for Boiler and Heat Exchanger Application
ASTM A213 alloy T5 has several elements such as silicon, molybdenum, nickel, chromium, manganese, vanadium. This alloying element helps to increase wear resistance, toughness and strength. A213 T5 tubing serves industries such as petrochemical, power generation, sugar mills, pulp & paper, heat recovery steam generation, etc. sa213 T5 material properties of hot strength make it suitable for use in pressure bearing plants having operating temperature of up to 1000°C.
| Tube Sizes for Heat Exchangers & Condensers & Boiler | |||||||||
| Outside Diameter | BWG | ||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| Wall Thickness mm | |||||||||
| 0.508 | 0.71 | 0.89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
| mm | inch | Weight kg/m | |||||||
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
ASTM A213/ASME SA213 T5 Alloy Steel Seamless Tube Chemical Composition(%)
| Grade | Chemical Composition(%) | ||||||
| C | Mn | P | S | Si | Cr | Mo | |
| A213 T5 | ≤0.15 | 0.30-0.60 | ≤0.025 | ≤0.025 | ≤0.50 | 4.00-6.00 | 0.45-0.65 |
ASTM A213/ASME SA213 T5 Alloy Steel Seamless Tube Mechanical & Physical Properties
| Grade | Mechanical property | |||
| Tensile Strength(MPa) | Yield Strength(MPa) | Elongation(%) | Hardness(HB) | |
| A213 T5 | ≥415 | ≥205 | 30 | ≤163 |
Note: Mechanical property requirements do not apply to tubing smaller than 1⁄8 in. [3.2 mm] in inside diameter or thinner than 0.015 in. [0.4 mm] in thickness.
ASTM A213/ASME SA213 T5 Alloy Steel Seamless Tube Size Tolerance
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
|
Trade Name |
Grade |
UNS # |
Heater Tubes |
|
1 1/4 Chrome |
T11 |
K11597 |
A213 / SA213 |
|
2 1/4 Chrome |
T22 |
K21590 |
A213 / SA213 |
|
5 Chrome |
T5 |
K41545 |
A213 / SA213 |
|
9 Chrome |
T9 |
K90941 |
A213 / SA213 |
|
T91 |
T91 |
K90901 |
A213 / SA213 |
|
T92 |
T92 |
K92460 |
A213 / SA213 |
Applications
-
Power Generation
-
Petrochemical Industry
-
Oil and Gas
-
Automotive
-
Aerospace
-
Heat Exchangers
-
Boilers
