ASTM A789 S31803 Seamless Tube OD 6-219mm Chloride Resistant Chlor-Alkali Processing
ASTM A789 S31803 Seamless Tube OD 6-219mm Chloride Resistant Chlor-Alkali Processing
ASME SA789 S31803 stainless steel tubing provides better pitting and crevice corrosion resistance than 316L or 317L austenitic stainless steel in almost all corrosive media. It also has high corrosion and erosion fatigue properties, as well as lower thermal expansion rates and higher thermal conductivity compared to austenitic stainless steels. The advantage of a duplex structure is that it combines the advantages of ferritic alloys, stress corrosion resistance, crack resistance, and high strength with the ease of manufacture and corrosion resistance of austenitic alloys.
Chemical Composition
| Grade |
C max |
Si max |
Mn max |
P max |
S max |
Cr | Ni | Mo | N |
| UNS S32750 | 0.030 | 0.8 | 1.2 | 0.030 | 0.015 | 24.0-26.0 | 6.0-8.0 | 3.0-5.0 | 0.24-0.32 |
| UNS S31803 | 0.030 | 1.0 | 2.0 | 0.020 | 0.020 | 21.0-23.0 | 4.5-6.5 | 2.5-3.5 | 0.08-0.20 |
| UNS S31500 | 0.030 | 1.0 | 1.2-2.0 | 0.030 | 0.030 | 18.0-19.0 | 4.5-5.5 | 2.5-3.5 | 0.05-0.10 |
Physical Properties
| Grade | Y.S.MPa min | T.S.Mpa min | Elongation % | Hardness HRC |
| UNS S32750 | 550 | 800 | 15 | 20 |
| UNS S31803 | 450 | 620 | 25 | 20 |
| UNS S31500 | 440 | 630 | 30 |
20 |
Heat Treatment Requirements
| UNS
Designation |
Temperature | Quench |
| S31803 | 1870-2010 °F [1020-1100°C] | Rapid cooling in air or water |
| S32205 | 1870-2010 °F [1020-1100°C] | Rapid cooling in air or water |
| S31500 | 1800-1900 °F [980-1040°C] | Rapid cooling in air or water |
| S32550 | 1900 °F [1040°C] min. | Rapid cooling in air or water |
| S31200 | 1920-2010 °F [1050-1100°C] | Rapid cooling in water |
| S31260 | 1870-2010 °F [1020-1100°C] | Rapid cooling in water |
| S32001 | 1800-1950 °F [982-1066°C] | Rapid cooling in air or water |
| S32304 | 1700-1920 °F [925-1050°C] | Rapid cooling in air or water |
| S32750 | 1880-2060 °F [1025-1125°C] | Rapid cooling in air or water |
| S32760 | 2010-2085 °F [1100-1140°C] | Rapid cooling in air or water |
| S32950 | 1820-1880 °F [990-1025°C] | Rapid cooling in water |
| S32520 | 1975-2050 °F [1080-1120°C] | Rapid cooling in air or water |
Duplex Stainless Steel Pipe Application
- Chemical processing
- Transport and Storage
- Oil and gas exploration and offshore rigs
- Oil and gas refining
- Marine environments
- Pollution control equipment
- Pulp and paper manufacturing
- Chemical process Plant
S31803 Tubes Ordering Information
Orders for product under this specification should in- clude the following, as required, to describe the desired material adequately:
- Quantity (feet, metres, or number of lengths)
- Name of product (seamless or welded tubes)
- Grade
- Size (outside diameter and average wall thickness, unless minimum wall thickness is specified)
- Length (specific or random)
- Special requirements
