ASME SB111 UNS C70600, Cu-Ni 90/10, CuNi10Fe1Mn Copper Nickel Alloy Seamless Tube
ASME SB111 UNS C70600, Cu-Ni 90/10, CuNi10Fe1Mn Copper Nickel Alloy Seamless Tube
ASTM B111 UNS C70600, also known as Cu-Ni 90/10, is a copper-nickel alloy with a composition of 90% copper and 10% nickel. UNS C70600 Copper Nickel Alloy Seamless Tube is usually used in a variety of applications, including marine system, chemical industry, heat exchangers, coolers, food processing equipments, construction and so on. Copper Nickel 90/10 alloy tubes are well-known for their excellent corrosion resistance, high strength and low magnetic permeability. These copper nickel alloy seamless tubes are also easy to fabricate and have excellent formability.
Characteristics:
- Thermal Conductivity
- Good Conductivity
- Good Wear Resistance
- Excellent Plasticity
- Good Cold Bending Property
- Easy To Welding and Machining
- Strong Seawafer Corrosion Resistance
Chemical Composition (%):
| Cu | Pb | Mn | Fe | Zn | Ni |
| 88.6 min | 0.05 max | 1.0 max | 1.8 max | 1 max | 9-11 max |
Mechanical Properties:
| Properties | Metric | Imperial |
| Tensile Strength, ultimate | 303-414 MPa | 43900-60000 psi |
| Tensile strength, yield (depending on temper) | 110-393 MPa | 16000-57000 psi |
| Elongation at break (in 254 mm) | 42.00% | |
Thermal Properties:
| Treatment | Minimum | Maximum |
| Annealing | 1100°F | 1500°F |
| Hot Working Temperature | 1550°F | 1750°F |
Applications:
- Chillers
- Condensers
- Heat Exchangers
- Power Plants
- Refineries
- Desalination Plants
- Ship Building Equipments
- Defence
- Evaporators
- Chemical Industry
- Petrochemical Industry
- High Temperature Application
