China ASME SB622 Hastelloy C22 UNS N06022 DIN 2.4602 Nickel Alloy Steel Tube for Oil and Gas Industry for sale

ASME SB622 Hastelloy C22 UNS N06022 DIN 2.4602 Nickel Alloy Steel Tube for Oil and Gas Industry

Name: ASME SB622 Hastelloy C22 UNS N06022 DIN 2.4602 Nickel Alloy Steel Tube for Oil and Gas Industry
Brand: Yuhong Group Co.,Ltd

Price Negotiable

Price: Negotiable

MOQ: 1000KGS

Delivery Time: 10days->

Brand: Yuhong

Product Description

ASME SB622 Hastelloy C22 UNS N06022 DIN 2.4602 Nickel Alloy Steel Tube for Oil and Gas Industry

Alloy C22 is a nickel, chromium and molybdenum superalloy reinforced with solid solution, with a nominal chemical composition of 56% nickel, 22% chromium and 13% molybdenum, with additions of iron, tungsten and cobalt. It is commonly referred to by the trade name HastelloyASTM B622 Hastelloy C22 N06022 2.4602 Nickel Alloy Seamless Tube C22 and the universal designation UNS N06022.

Chemical composition of Hastelloy C22

Element	Content (%)
Chromium, Cr	20-22.5
Molybdenum, Mo	12.5-14.5
Tungsten, W	2.5-3.5
Cobalt, Co	2.5 min
Iron, Fe	2.0-6.0
Manganese. Mn	0.5 max
Vanadium, V	0.35 max
Silicon, Si	0.08 max
Phosphorus, P	0.02 max
Sulfur, S	0.02 max
Carbon, C	0.015 max
Nickel, Ni	Remainder

Hastelloy C22 Equivalent Grade

Grade	WERKSTOFF NR.	UNS
Hastelloy C22	2.4602	N06022

ASTM B622 Hastelloy C22 Seamless Tube Weight Chart

OD inches	Ave. Wall inches	D/t Ratio	ID inches	Tube Cross Sectional Area (in2)	Internal Area (in2)
0.250	0.020	12.50	0.210	0.0145	0.0346
0.250	0.028	8.93	0.194	0.0195	0.0296
0.250	0.035	7.14	0.180	0.0236	0.0254
0.250	0.049	5.10	0.152	0.0309	0.0181
0.250	0.065	3.85	0.120	0.0378	0.0113
0.375	0.020	18.75	0.335	0.0223	0.0881
0.375	0.028	13.39	0.319	0.0305	0.0799
0.375	0.035	10.71	0.305	0.0374	0.0731
0.375	0.049	7.65	0.277	0.0502	0.0603
0.375	0.065	5.77	0.245	0.0633	0.0471
0.500	0.020	25.00	0.460	0.0302	0.1662
0.500	0.028	17.86	0.444	0.0415	0.1548
0.500	0.035	14.29	0.430	0.0511	0.1452
0.500	0.049	10.20	0.402	0.0694	0.1213
0.500	0.065	7.69	0.370	0.0888	0.1075
0.500	0.083	6.02	0.334	0.1087	0.0876
0.625	0.020	31.25	0.585	0.0380	0.2688
0.625	0.028	22.32	0.569	0.0525	0.2543
0.625	0.035	17.86	0.555	0.0649	0.2419
0.625	0.049	12.76	0.527	0.0887	0.2181
0.625	0.065	9.62	0.495	0.1144	0.1924
0.625	0.083	7.53	0.459	0.1413	0.1655
0.625	0.095	6.58	0.435	0.1582	0.1486
0.625	0.109	5.73	0.407	0.1767	0.1301
0.750	0.028	26.79	0.694	0.0635	0.3783
0.750	0.035	21.43	0.680	0.0786	0.3632
0.750	0.049	15.31	0.652	0.1079	0.3339
0.750	0.065	11.54	0.620	0.1399	0.3019
0.750	0.083	9.04	0.584	0.1739	0.2679
0.750	0.095	7.89	0.560	0.1955	0.2463
0.750	0.109	6.88	0.532	0.2195	0.2223
0.750	0.120	6.25	0.510	0.2375	0.2043
0.875	0.020	43.75	0.835	0.0537	0.5476
0.875	0.028	31.25	0.819	0.0745	0.5268
0.875	0.035	25.00	0.805	0.0924	0.5090
0.875	0.049	17.86	0.777	0.1272	0.4742
0.875	0.065	13.46	0.745	0.1654	0.4359
0.875	0.083	10.54	0.709	0.2065	0.3948
0.875	0.095	9.21	0.685	0.2328	0.3685
0.875	0.109	8.03	0.657	0.2623	0.3390
0.875	0.120	7.29	0.635	0.2846	0.316L7
1.000	0.028	35.71	0.944	0.0855	0.6999
1.000	0.035	28.57	0.930	0.1061	0.6793
1.000	0.049	20.41	0.902	0.1464	0.6390
1.000	0.065	15.38	0.870	0.1909	0.5945
1.000	0.083	12.05	0.834	0.2391	0.5463
1.000	0.095	10.53	0.810	0.2701	0.5153
1.000	0.109	9.17	0.782	0.3051	0.4803
1.000	0.120	8.33	0.760	0.3318	0.4536
1.000	0.134	7.46	0.732	0.3646	0.4208
1.250	0.035	35.71	1.180	0.1336	1.0936
1.250	0.049	25.51	1.152	0.1849	1.0423
1.250	0.065	19.23	1.120	0.2420	0.9852
1.250	0.083	15.06	1.084	0.316L3	0.9229
1.250	0.095	13.16	1.060	0.3447	0.8825
1.250	0.109	11.47	1.032	0.3907	0.8365
1.250	0.120	10.42	1.010	0.4260	0.8012
1.250	0.134	9.33	0.982	0.4698	0.7574
1.500	0.035	42.86	1.430	0.1611	1.6061
1.500	0.049	30.61	1.402	0.2234	1.5438
1.500	0.065	23.08	1.370	0.2930	1.4741
1.500	0.083	18.07	1.334	0.3695	1.3977
1.500	0.095	15.79	1.310	0.4193	1.3478
1.500	0.109	13.76	1.282	0.4763	1.2908
1.500	0.120	12.50	1.260	0.5202	1.2469
1.500	0.134	11.19	1.232	0.5750	1.1921
1.500	0.148	10.14	1.204	0.6286	1.1385
1.750	0.035	50.00	1.680	0.1886	2.2167
1.750	0.049	40.82	1.902	0.3003	2.8413
1.750	0.065	26.92	1.620	0.3441	2.0612
1.750	0.083	21.08	1.584	0.4347	1.9706
1.750	0.095	18.42	1.560	0.4939	1.9113
1.750	0.109	16.06	1.532	0.5619	1.8433
1.750	0.120	14.58	1.510	0.6145	1.7908
1.750	0.134	13.06	1.482	0.6803	1.7250
1.750	0.148	11.82	1.454	0.7449	1.6604
1.750	0.165	10.61	1.420	0.8216	1.5837
2.000	0.035	57.14	1.930	0.2161	2.9255
2.000	0.049	40.82	1.902	0.3003	2.8413
2.000	0.065	30.77	1.870	0.3951	2.7465
2.000	0.083	24.10	1.834	0.4999	2.6417
2.000	0.095	21.05	1.810	0.5685	2.5730
2.000	0.109	18.35	1.782	0.6475	2.4941
2.000	0.120	16.67	1.760	0.7087	2.4328
2.000	0.134	14.93	1.732	0.7855	2.3561
2.000	0.148	13.51	1.704	0.8611	2.2805
2.000	0.165	12.12	1.670	0.9512	2.1904

ASME SB622 Hastelloy C22 UNS N06022 DIN 2.4602 Nickel Alloy Steel Tube Applications

-Petrochemical
-Oil & Gas
-Paper
-Refineries
-Nuclear Power
-Cement
-Sugar
-Power Plant
-Fertilizers
-Breweries
-Chemical
-Petrochemical
-Shipbuilding
-Defence
-Mining
