ASME BPE Compliant TP316L Seamless Tube for Analytical Equipment
ASME BPE Compliant TP316L Seamless Tube for Analytical Equipment
Yuhong Special Steel has been dealing with seamless stainless steel tubes for more than 10 years. Our customers have covered more than 45 countries. Our seamless stainless steel tubes are widely used in mining, energy, petrochemical, chemical, food mill, paper mill, gas and fluid industries.
ASTM A269 Stainless Steel Welded Coiled Tube
(1)Commodity name: Austenitic Stainless Steel Coil Tubes
(2)Process method: cold drawn/cold pilgered
(3)Material: TP304, TP304L,TP316L,dual grade 317L , 316Ti, TP321
(4)Standard: ASTM ( ASME) ,EN, DIN, JIS and etc.
(5)Specifications:a) O.D.:1/4" -3/4"
b) W.T.:0.028"- 0.065"
c) Length:customized, max:500m/pc.
(6)Delivery conditions: annealed & pickled
(7)Applications: widely used in petrol, chemical, pharmacy, foodstuff, machinery, spaceflight,
war industry.
(8)boiler gas, hot water heating parts, hardware, shipping, power and other
industries.
(9)Packing: packed by weaving bags, then protected by seaworthy wooden case.
|
American Standard |
Austenitic Steel: |
|
Europen Standard |
1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
|
GOST |
08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, |
| Imperial size | Metric size | ||
| OD inch |
WT inch |
OD mm |
WT mm |
| 1/8 (0.125) | 0.028 | 3.18 | 0.71 |
| 0.035 | 3.18 | 0.89 | |
| 3/16 (0.188) | 0.028 | 4.76 | 0.71 |
| 0.035 | 4.76 | 0.89 | |
| 0.049 | 4.76 | 1.24 | |
| 1/4 (0.250) | 0.035 | 6.35 | 0.89 |
| 0.049 | 6.35 | 1.24 | |
| 0.065 | 6.35 | 1.65 | |
| 0.083 | 6.35 | 2.11 | |
| 3/8 (0.375) | 0.035 | 9.53 | 0.89 |
| 0.049 | 9.53 | 1.24 | |
| 0.065 | 9.53 | 1.65 | |
| 0.083 | 9.53 | 2.11 | |
| 1/2 (0.500) | 0.035 | 12.7 | 0.89 |
| 0.049 | 12.7 | 1.24 | |
| 0.065 | 12.7 | 1.65 | |
| 0.083 | 12.7 | 2.11 | |
ASTM A269 Stainless Steel Welded Coiled Tube Test Requirement
- Quality Requirement: Mill Test Certificate will be supplied with shipment , Third Part Inspection is acceptable
- Test NTD ( Ultrasonic test , Eddy Current test )
- Mechanical Test ( Tension Test , Flaring Test , Flattening Test , Hardness Test , Hydraulic test )
- Metal Test ( Metallographic Analysis , Impact Test - High / low temperature )
- Chemical Analysis ( Photoelectric Emission Spectroscopic )
