ASTM A269 TP304 Stainless Steel Seamless Tube Pickled and Annealed Tubing
ASTM A269 TP304 Stainless Steel Seamless Tube Pickled and Annealed Surface
ASTM A269 standard covers grades of welded/seamless stainless steel such as TP304, TP304L, TP316, TP316L, and other austenitic grades commonly used in various industries, including food processing, pharmaceuticals, chemical processing, oil and gas, and other applications that require high corrosion resistance and cleanliness.
TP304 Stainless Steel Seamless Tube Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
ASTM A269 TP304 Stainless Steel Seamless Tubes range
| ASTM A269 TP304 Stainless Steel Tubes Specification | ASTM A-249, A-268, A-269, A-270, A-554, A-688, A-778, DIN 17455, DIN 17456, 17457, DIN 17458 [Class 1] & Its equivalent ASME, DIN & EN Standard. |
| ASTM A269 TP304 Stainless Steel Tubes Grades | 202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC. |
| ASTM A269 TP304 Stainless Steel Tubes Type | Seamless / Welded / ERW / EFW / Cold Draw / Hot Finish / Cold Finish |
| ASTM A269 TP304 Stainless Steel Tubes Length | Single Random Length, Double Random Length And Customize Size. |
| ASTM A269 TP304 Stainless Steel Tubes Ends | Plain Ends / Beveled Ends |
| ASTM A269 TP304 Stainless Steel Tubes Other Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiograph HIC Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
| ASTM A269 TP304 Stainless Steel Tubes Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM And ASME |
| ASTM A269 TP304 Stainless Steel Tubes Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment / Annealed / Bright Annealed |
| ASTM A269 TP304 Stainless Steel Tubes Packaging | Plywooden Case /Iron Case/ Bundle with plastic Cap/requirements |
Other Material Grades
|
American Standard |
Austenitic Steel: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Duplex Steel : S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439,... |
|
Europen Standard |
1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
|
GOST Standard |
08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
Pickled Surface: This refers to a surface finish obtained by chemical treatment, typically using an acid solution. The pickling process removes oxide scales and other impurities from the surface of the stainless steel tube, resulting in a clean and smooth surface.
Bright Annealed Surface: Bright annealing is a more controlled annealing process that is performed in a controlled atmosphere to prevent oxidation and discoloration of the stainless steel surface. It produces a clean, smooth, and bright surface finish, free from scale and discoloration.
Applications
- Food processing equipment, particularly in beer brewing, milk processing & wine making.
- Kitchen benches, sinks, troughs, equipment and appliances
- Architectural panelling, railings & trim
- Chemical containers, including for transport
- Heat Exchangers
- Woven or welded screens for mining, quarrying & water filtration
- Threaded fasteners
- Springs
- Ship building, onshore , offshore, Maire.
- Others
