EN10217-1 P235GH Weld Steel Non Alloy Steel Tube
EN10216-5 1.4541 Seamless Tube
EN10217-1 P235GH is a European standard specification for non-alloy steel tubes that are suitable for welding. These tubes are commonly used in the construction of pressure vessels, boilers, and pipelines.
The P235GH grade of steel is characterized by its good weldability and high strength, making it ideal for applications where high temperature and pressure resistance are required. The tubes are manufactured using hot-rolled or cold-formed steel and can be supplied in various shapes and sizes.
These non-alloy steel tubes are typically used in industrial applications where the materials are subjected to high temperatures and pressures. They are also commonly used in the construction of power plants, chemical plants, and other industrial facilities.
Overall, EN10217-1 P235GH weld steel non-alloy steel tubes are a reliable and cost-effective option for a wide range of industrial applications that require high strength and resistance to temperature and pressure.
P235GH chemical composition:
| C | Si | Mn | P | S | Cr | Cu | Ni | Mo |
| ≤0.16 | ≤0.35 | 0.6-1.2 | ≤0.025 | ≤0.01 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.08 |
P235GH pysical property:
| Grade | Tensile strength Rm | Yield strength YS | Enlongation A(％) |
| P235GH | 350 - 480 MPa at 20 °C | 185 - 235 MPa at 20 °C | >24 |
Applications
1. Pressure Vessels
2. Boilers
3. Heat Exchangers
4. Pipelines
5. Structural Applications
