ASTM A554 TP304 Stainless Steel Welded Pipe For Superior Chemical Composition
ASTM A554 TP304 Weld Pipe
Overview
ASTM A554 is a specification published by ASTM International that covers stainless steel mechanical tubing. However, there seems to be some confusion in your query as "TP304" is not directly associated with ASTM A554. Instead, TP304 refers to a specific grade of stainless steel, which is typically covered under different ASTM standards.
ASTM A554 TP304 Stainless Steel Welded Tube Chemical Composition
| Grade | Carbon | Nickel | Manganese | Sulfur | Chromium | Phosphorus | Silicon |
| 304 | 0.08 | 8.0-11.0 | 2 | 0.03 | 18.0-20.0 | 0.045 | 1 |
SA554 Grade Mt 304 Tubing Mechanical Properties
| Material | Temperure | Heat | Yield Strength | Tensile Strength | Elongation |
| Min.º F(º C) | Treatment | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| 304 | 1900 (1040) | Solution | 30(205) | 75(515) | 35 |
ASME SA554 Tp304 Square Pipe Equivalent
| Grade | Unified Numbering System | Euronorm | Old British | Swedish SS | Japanese Industrial Standards | ||
| No | Name | British Standards | European Standards | ||||
| ASTM A554 TP304 | S30400 | 1.4301 | X5CrNi18-10 | 304S31 | 58E | 2332 | SUS 304 |
ASTM A554 Type 304 Tube Physical Properties
Grade |
Mean Coefficient of Thermal Expansion (μm/m/°C) | Density (kg/m3) | Elastic Modulus (GPa) | Specific Heat 0-100°C (J/kg.K) | Thermal Conductivity (W/m.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| TP304 | 17.2 | 17.8 | 18.4 | 8000 | 193 | 500 | 16.2 | 21.5 | 720 |
Applications of ASTM A554 TP304 Welded Pipes:
1. Food Processing Industry
2. Pharmaceutical Industry
3. Chemical Processing Industry
4. Oil and Gas Industry
5. Architecture and Construction
6. Marine Applications
7. Heating, Ventilation, and Air Conditioning
8. Water Treatment Plants
9. Agricultural Equipment
