ASTM A269 TP304 Stainless Steel Seamless Tube Tubing Bright Annealed Finish
ASTM A269 TP304 / UNS S30400 Bright Annealed Stainless Steel Seamless Tube
Standard by ASTM International for seamless and welded austenitic stainless steel tubes used in high-temperature service, general corrosion resistance, and low-temperature applications. Seamless tubes made by piercing a solid billet and extruding/rolling it into a hollow tube with no welded seams, ensuring uniform strength. ASTM A269 TP304 stainless steel seamless tube are often supplied with a bright annealed finish (smooth, shiny, oxide-free surface) or pickled finish (matte appearance). Heat Treatment: Solution-annealed (heated and rapidly cooled) to restore corrosion resistance and ductility.
ASTM A269 TP304 Stainless Steel Seamless Tube Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
Chemical Composition of ASTM A270 TP304 Stainless Steel Seamless Tube
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 304 | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
Other Available Material Grades
|
American Standard |
Austenitic Steel: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Duplex Steel : S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439,... |
|
Europen Standard |
1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
|
GOST Standard |
08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
| Bright Annealed | Pickled Annealed |
|
Medical implants, semiconductor tubing, high-purity systems (no risk of contamination). Food/beverage equipment (easy to clean, hygienic). |
Chemical processing, oil/gas pipelines, structural components (cost-effective for large-scale use). Applications where surface finish is less critical. |
| Minimal surface disruption; retains the natural passive chromium oxide layer. Excellent corrosion resistance in most environments. |
Pickling removes contaminants and scale, exposing a fresh surface.New passive layer forms after passivation, enhancing corrosion resistance. May perform better in aggressive environments due to thorough oxide removal. |
Applications
- Food processing equipment, particularly in beer brewing, milk processing & wine making.
- Kitchen benches, sinks, troughs, equipment and appliances
- Architectural panelling, railings & trim
- Chemical containers, including for transport
- Heat Exchangers
- Ship building, onshore , offshore, Maire.
