ASTM B462 Hastelloy C276 Nickel Alloy UNS N10276 Weld Neck Flange WNRF

ASME B16.5 Hastelloy C276 Flange ASTM B462 UNS N10276 / 2.4819 Nickel Alloy WNRF Flange

Hastelloy C276 (UNS N10276/ 2.4819) is a nickel-chromium-molybdenum-tungsten superalloy renowned for exceptional corrosion resistance in extreme environments. Key features:

• Composition: 57% Ni, 15–17% Mo, 14.5–16.5% Cr, 3–4.5% W, and ultra-low carbon (≤0.01%) to prevent carbide precipitation during welding.

• Corrosion Resistance: Withstands pitting, crevice corrosion, and stress corrosion cracking (SCC) in oxidizing/reducing media, including sulfuric, hydrochloric, and phosphoric acids, chlorides, and sour (H₂S) environments. Its PREn (Pitting Resistance Equivalent) of ~69 outperforms most stainless steels.

• Temperature Range: Retains strength and oxidation resistance up to 1,040°C (1,900°F), though prolonged exposure above 540°C risks carbide formation.

• Testing/Certification: Complies with NACE MR0175 for sour service and ASTM B462 for wrought components. PT/RT testing is critical for high-integrity welds.

• Hidden Strengths: Tungsten enhances stability in mixed acids, while electropolishing mitigates post-weld corrosion. Avoids gamma prime phase embrittlement, unlike age-hardenable alloys.

Equivalent Grades of ASTM B462 Hastelloy C276 Flange Nickel Alloy UNS N10276 Weld Neck Flange

Chemical Composition of of ASTM B462 Hastelloy C276 Flange Nickel Alloy UNS N10276 Weld Neck Flange

-N10276 Welding Neck Flange(WNF) & Long Welding Neck Flange(LWNF)
-N10276 Slip-on Flange(SOF)
-Lap Joint Flange(LJW)
-N10276 bind Flange
-Socket Welding Flange (SWF)
-Threaded Flange(THW)
-Plate Flange

ASTM/ASME/ANSIB16.5, B16.47, ASME/ANSI B16.48 flange
slip on flange, Weld Neck Flange ,Threaded Flange Blind Flange

Application

• Chemical Processing: Reactors, heat exchangers, and piping in HCl, H₂SO₄, and acetic acid environments.

• Oil & Gas: Subsea pipelines, downhole tools, and sour gas handling.

• Pollution Control: Flue gas desulfurization (FGD) systems.

• Pharmaceutical: High-purity systems requiring contamination resistance.

• Marine: Seawater cooling systems and offshore platforms.
