ASME SA213 TP321 S32100 Stainless Steel Seamless Tube For Superheater
ASME SA213 TP321 S32100 Stainless Steel Seamless Tube for Superheater Application
With over 30 years of industry experience in stainless steel tube, Yuhong Company exports to 85 countries, trusted globally in superheater applications.
Our ASME SA213 TP321 S32100 Stainless Steel Seamless Tube meets ASME SA213 standards, using high-quality S32100 stainless steel. It resists high temperatures, oxidation, and corrosion, ensuring stable operation in superheaters.
ASME SA213 TP321 S32100 Stainless Steel Seamless Tube Chemical Composition
| Grade | UNS Designation | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel |
Titanium
|
| TP321 | S32100 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0 - 19.0 | 9.0 - 12.0 |
4(C + N)–
0.70
|
ASME SA213 TP321 Equivalent specification
| Region | Standard System | Designation |
| China | GB | 06Cr18Ni11Ti |
| Japan | JIS | SUS 321 |
| South Korea | KS | STS 321 |
| USA | ASTM | 321 |
| USA | UNS | S32100 |
| ISO | ISO | X6CrNiTi 18 - 10 |
| ISO | Numerical Designation | 4541 - 321 - 00 - I |
| Germany | DIN EN/DIN | X6CrNiTi 18 - 10 (X10CrNiTi 18 - 9) |
| Germany | W - Nr. | 1.4541 |
| France | NF EN/NF | Z6CNT 18 - 10 |
| Europe | EN | X6CrNiTi 18 - 10 |
| Europe | Numerical Designation | 1.4541 |
| Russia | GOST | 09X18H10T X18H10T |
| Sweden | SS | 2337 |
| UK | BS EN/BS | 321S12 321S31 |
Heat Treatment and Grain Size Requirements
| Grade | UNS Number | Heat Treat Type | Austenitizing/Solutionizing/Stabilizing Temperature | Cooling Media |
| TP321 | S32100 | solution treatment | 1900 [1040]°F | water or other rapid cool |
Tensile and Hardness Requirements
| Gade | UNS | Tensile Strength | Yield Strength | Elongation | Hardness | |
| TP321 | S32100 | min, ksi[MPa] | min, ksi[MPa] | in 2 in. or 50 mm, min, % | Brinell/Vickers | Rockwell |
| 75[515] | 30[205] | 35 | 192 HBW | 90 HRB | ||
| 200 HV | ||||||
ASME SA213 TP321 S32100 Stainless Steel Seamless Tube for Superheater Application
- 1. High-Temperature Endurance
- Can stably work under superheater’s high-temperature conditions (e.g., common 500 - 800°C). Titanium in the alloy stops “sensitization”, avoiding intergranular corrosion even after long-term heat exposure, ensuring effective steam heating.
- 2. Corrosion Resistance
- Resists oxidation from superheater’s oxygen-rich gases and steam. Also fends off flue gas-related corrosive substances, reducing damage and extending tube service life.
- 3. Mechanical Reliability
- Under high pressure and thermal stress in superheaters, it has good creep and stress-rupture resistance. Maintains shape and structure, preventing deformation or rupture-caused failures.
