ASTM B111 C71500 Copper Nickel Tube Superior Seawater Corrosion Resistance For Heat Exchangers
ASTM B111 C71500 Copper Nickel Tube (90-10 CuNi) | Seawater Corrosion Resistant Tubes Supplier
Brief Introduction
ASTM B111 C71500 Copper Nickel (90-10 CuNi) Tubes are engineered for extreme corrosion resistance in marine and industrial environments. As a premier supplier, we provide seamless and welded tubes compliant with ASTM B111 standards, delivering unmatched performance in heat exchangers, condensers, and offshore applications.
Chemical Composition (ASTM B111 Compliance)
|
Element |
Composition (%) |
ASTM B111 Requirement |
|---|---|---|
|
Copper (Cu) |
88.6 - 90.0 |
Balance |
|
Nickel (Ni) |
9.0 - 11.0 |
9.0 - 11.0 |
|
Iron (Fe) |
1.3 - 1.8 |
1.0 - 1.8 |
|
Manganese (Mn) |
0.3 - 0.8 |
0.30 - 1.0 |
|
Lead (Pb) |
≤ 0.02 |
≤ 0.05 |
|
Zinc (Zn) |
≤ 0.20 |
≤ 0.50 |
|
Other Impurities |
≤ 0.3 |
≤ 0.5 (Total) |
Equivalent Grades & International Standards
|
Region |
Standard |
Equivalent Grade |
|---|---|---|
|
USA |
ASTM B111 |
C71500 |
|
Europe |
EN 12451 |
CuNi10Fe1Mn |
|
Germany |
DIN 17664 |
2.0872 |
|
Japan |
JIS H3500 |
C7150 |
|
ISO |
ISO 1634 |
CuNi10Fe1Mn |
C71500 Mechanical Properties ASTM B111
|
Property |
Annealed Condition |
Hard Temper (Drawn) |
|---|---|---|
|
Tensile Strength (min) |
45 ksi (310 MPa) |
60 ksi (415 MPa) |
|
Yield Strength (0.2% offset) |
15 ksi (105 MPa) |
45 ksi (310 MPa) |
|
Elongation (in 2") |
35% min |
15% min |
|
Hardness (Rockwell B) |
45 HRB |
85 HRB |
Key Advantages
Superior Seawater Corrosion Resistance
- Low corrosion rate (<0.025 mm/year) in flowing seawater.
- Resists pitting and stress corrosion cracking in chloride environments.
Biofouling Resistance
- Inhibits marine organism attachment – reduces maintenance costs.
High Thermal Conductivity
- 29 W/m·K (vs. 16 W/m·K for 316 stainless steel) – ideal for heat exchangers.
Erosion Resistance
- Withstands high-velocity seawater (up to 3.5 m/s).
Application Fields
|
Industry |
Critical Applications |
|---|---|
|
Marine Engineering |
Shipboard condensers, seawater piping, desalination plants |
|
Power Generation |
Steam condenser tubes, heat exchanger tubing |
|
Oil & Gas |
Offshore platform cooling systems, brine heat exchangers |
|
Chemical Processing |
Acid cooling systems, evaporator tubes |
|
Desalination |
Multi-stage flash (MSF) evaporator tubes |
