SUS304 Stainless Steel Capillary Medical Tube For Syringes Catheters ISO9626
SUS304 Stainless Steel Capillary Medical Tube For Syringes And Catheters ISO9626
Stainless steel capillary tubes are hollow, slender, high-precision tubes, which have tight dimension tolerance and smooth surface finish. YUHONG GROUP has manufactured and supplied stainless steel capillary tubes for more than 30 years. Our medical capillary tubes are mainly made by stainless steel 304 grades due to excellent corrosion resistance and durability. They are used in medical devices such as syringes, catheters, and diagnostic equipments. The diameter sizes range from 0.15 to 3.4mm or can be customized, and the tube length can be cut into fixed length, such as 1 or 2meter. We can also meet clients’ requirements about tube shapes through cutting, flaring, swaging, bending, slotting, punching etc.. And capillary tubes can be designed based on clients’ drawings or samples.
Key Characteristics Of Medical Grade Stainless Steel Capillary Tubes:
- Complied With ISO9626: 2016 International Standard
- Excellent Surface Finish
- High Strength
- Good Resistance to Corrosion
- High Precision and Strict Size Tolerance
- Good formability and Durability
- Temperature Resistance
Chemical Composition:
| Grades | UNS | C | Mn | P | S | Si | Cr | Ni | Mo |
| SUS304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | - |
| SUS316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
Mechanical Characteristics:
| Material | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| º F(º C) | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| Min. | ||||
| SUS304 | 1900 (1040) | 75(515) | 30(205) | 35 |
| SUS316L | 1900(1040) | 70(485) | 25(170) | 35 |
Applications Of Medical Capillary Tubes:
- Medical Syringe Needle
- Injection Needle
- Insulin Needle
- Hypodermic Needle
- Dental Needle
- Biopsy Needle
- EMG Needle
- AV Fistula Needle
- Mesotherapy Needle
- Intravenous Indwelling Needle
- Scalp Vein Needle
- Puncture Needle
- Blunt Needle
- Veterinary Needle
- Laboratory and Scientific Instruments
