ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
Price:
Negotiable
MOQ:
1PC
Delivery Time:
7 DAYS
Brand:
YUHONG
Product Description
ASTM A182 F11 CL2 Alloy Steel Forged Sockolet for High Pressure Service
A Sockolet is a type of branch connection fitting manufactured by a company called Bonney Forge (now part of PCC Energy Group). The name has become generic, much like "Kleenex" for tissues. It is used to create a 90-degree branch from a main run pipe without the need for a separate tee fitting.
- Design: It has a socket-weld outlet on the branch side and a butt-weld connection on the run side (the header). The branch pipe is inserted into the socket and fillet-welded.
- Purpose: It provides a strong, reinforced branch connection that is ideal for small-bore piping (typically NPS 2" and below) in high-pressure systems. It is more compact and offers better flow characteristics than a threaded coupling or a saddle-type connection.
ASTM A182 F11 CL2 Alloy Steel Forged Fitting Sockolet Equivalent Grade
| Brand Name | Ravne No. | Mat. No. | DIN | EN | AISI |
| 13CRMO44 | 762 | 1.7335 | 13CrMo44 | 13CrMo4-5 | A 182 Grade F11 |
ASTM A182 F11 CL2 Alloy Steel Forged Fitting Sockolet Chemical Composition (%)
| C | Si | Mn | Cr | Mo | P | S |
| 0.1-0.2 | 0.5-1.0 | 0.3-0.8 | 1.0-1.5 | 0.44-0.65 | 0.04 max | 0.04max |
Comparison Table: F11 vs. Common Alternatives
| Feature | ASTM A182 F11 CL2 | ASTM A105 (Carbon Steel) | ASTM A182 F22 (Grade 22) | ASTM A182 F316L (Stainless) |
|---|---|---|---|---|
| Primary Use | High-Temp Steam & Process | Low-Temp Utility Services | Higher Temp/Pressure than F11 | Corrosion Resistance |
| Key Elements | 1.25% Cr, 0.5% Mo | Carbon, Manganese | 2.25% Cr, 1.0% Mo | 17% Cr, 12% Ni, 2.5% Mo |
| Temp Range | Up to ~1000°F (538°C) | Up to ~800°F (427°C) | Up to ~1200°F (649°C) | Varies (for corrosion) |
| Main Advantage | Balanced strength & weldability | Low Cost | Superior Creep Strength | Excellent Corrosion Resistance |
| Weldability | Good (with pre/PWHT) | Excellent | Requires careful procedure | Excellent |
Specification
| Standard | Types | Class Rating/Schedule | Ends | Size |
| ASME B16.11 | 90°Elbow/ 45°Elbow/ Tee/ Cross/Pipe Cap/ Half Coupling/Full Coupling | 3000LB/6000LB | Threaded | 1/4''~4'' |
| Socket-welding | 1/8''~4'' | |||
| 90°Elbow/ 45°Elbow/ Tee/ Cross/Half Coupling/Full Coupling | 9000LB | Socket-welding | 1/2''~2'' | |
| Street Elbow | 3000LB | Threaded | 1/8''~2'' | |
| 6000LB | 1/8''~1-1/2'' | |||
| Lateral Tee | 3000LB | Socket-welding | 1/4''~2'' | |
| 6000LB | 1/2''~1-1/2'' | |||
| 3000LB | Threaded | 3/8''~2‘’ | ||
| 6000LB | 1/2''~2'' | |||
| 9000LB | 1/2''~1-1/2'' | |||
| Flush Bushing/Hex Bushing/Hex Plug/Round Plug/Square Plug | 3000LB/6000LB | Threaded | 1/8''~4'' | |
| MSS SP79 | Reducer Inserts | 3000LB/6000LB/9000LB | Socket-welding | 3/8‘’x1/4''~2x1/2'' |
| MSS SP83 | Union | 3000LB | Socket-welding/Threaded | 1/8''~3'' |
| MSS SP95 | Concentric/Eccentric Swaged Nipples | See Below Note1 | 1/4‘’~12'' | |
| Bull Plugs | Threaded | 1/8''~12'' | ||
| MSS SP97 | Weldolet | STD, XS, Sch 160/XXS | Butt-welding | 1/8''~36‘’ or larger |
| Sockolet | 3000LB/6000LB | Socket-welding | 1/8''~6'' | |
| Threadolet | 3000LB/6000LB | Threaded | 1/8''~6'' | |
| Nipolet | XS/XXS | Plain/Threaded | 1/2''~2'' | |
| Elbolet | 3000LB/6000LB | Socket-welding/Threaded | 1/4''~2'' | |
| STD/XS/160/XXS | Butt-welding | 1/4''~2-1/2'' or larger | ||
| Latrolet | 3000LB/6000LB | Socket-welding/Threaded | 1/2''~2'' | |
| STD/XS/160/XXS | Butt-welding | 1/2''~2-1/2'' | ||
| Flangolet,Nipolet,Sweepolet,etc. available as per client' demands. | ||||
