A335 P9 HFW Finned Tubes For High Temp Heat Exchangers Carbon Steel Fins
Price:
Negotiable
MOQ:
10PCS
Delivery Time:
Depends on quantity
Brand:
YUHONG
Product Description
High-Frequency Welded Finned Tubes (Base Tube: A335 P9 / Fins: Carbon Steel CS)
1. A335 P9 + CS Finned Tube Core Technology
High-frequency welded finned tubes integrate A335 P9 chromium-molybdenum alloy base tubes with carbon steel (CS) fins. This synergy delivers exceptional heat transfer efficiency (up to 98% weld integrity) and resistance to thermal stress (operating range: -50°C to 580°C). Ideal for high-pressure, corrosive industrial applications.
2. Precision Manufacturing Process
Our high-frequency welding (HFW) ensures metallurgical bonding without filler metals:
- Surface Prep: Base tube grit-blasted to Sa 2.5 (ISO 8501-1).
- Fin Winding: Fins spirally wound at 3–6 RPM under 150–300 MPa tension.
- HFW Bonding: 400–800 kHz frequency creates a seamless fin-to-tube interface.
- Post-Weld Treatment: Stress-relieved at 650°C ±15°C (ASME Section IX compliant).
3. Chemical Composition: ASTM-Compliant Materials
| Component | A335 P9 Base Tube (%) | Carbon Steel Fins (%) |
|---|---|---|
| Carbon (C) | 0.15 max | 0.25–0.35 |
| Chromium (Cr) | 8.0–10.0 | ≤ 0.40 |
| Molybdenum (Mo) | 0.90–1.10 | ≤ 0.15 |
| Silicon (Si) | 0.50–1.00 | 0.15–0.35 |
| Manganese (Mn) | 0.30–0.60 | 0.60–1.20 |
| Sulfur (S) | 0.025 max | 0.04 max |
4. Dimensional Tolerances: Precision Engineering
| Parameter | Base Tube (A335 P9) | Fins (CS) |
|---|---|---|
| Outer Diameter | ±0.20 mm | ±0.05 mm |
| Thickness | ±10% nominal | ±0.03 mm |
| Fin Height | N/A | ±0.15 mm |
| Fin Density | N/A | 150–400 fins/meter |
| Straightness | ≤1.5 mm/m length | ≤1.0 mm/m length |
5. High-Temperature Application Domains
- Power Generation: Boiler economizers (450–550°C), flue gas heat recovery.
- Petrochemical: Crackers, reformers, and sulfur recovery units (H₂S resistance).
- HVAC Systems: Industrial air preheaters (250–400°C).
- Renewable Energy: Biomass/waste-to-energy boilers (abrasion-resistant).
- Marine Engineering: Exhaust gas boilers (salt spray corrosion protection).
6. Advantages & Performance Validation
- Thermal Stability: P9’s 9% Cr content reduces oxidation at >540°C.
- Mechanical Strength: Tensile strength: ≥415 MPa (base), ≥310 MPa (fins).
- Corrosion Resistance: CS fins + P9 base withstand pH 3–12 environments.
- Quality Assurance: 100% eddy current testing, hydrostatic pressure checks (40 MPa).
- Proven Expertise: 12+ years supplying EU/NA power plants with zero field failure.
Why Choose Us?
✅ Customizable fin configurations (L-foot, embedded, serrated).
✅ ASME B36.10M, EN 10204-3.1 certified.
✅ Lead time: 30–45 days (MOQ: 500 meters).
