ASTM B163 / B167 INCONEL600 SEAMLESS TUBING , ANNEALED, 100% EDDY CURRENT TEST AND HYDROSTATIC TEST
Price:
negotiable
MOQ:
1PC
Delivery Time:
Negotiable
Brand:
YUHONG
Product Description
ASTM B163 / B167 INCONEL600 SEAMLESS TUBING, ANNEALED, 100% EDDY CURRENT TEST AND HYDROSTATIC TEST
Inconel 600 , 601 , 625, 690, 718, X-750
Typical Mechanical Properties
Various forms and conditions
| Form and Condition | Tensile Strength | 0.2% Yield Strength | % Elongation in 2" | % Reduction of Area | Rockwell Hardness | ||
| Rod and Bar Cold-drawn Annealed As-drawn Hot rolled Annealed As-rolled Hot-finished Strip Annealed | 80-100 105-150 80-100 85-120 80-120 80-100 | 552-689 724-1034 552-689 586-827 586-827 552-689 | 25-50 80-125 30-50 35-90 35-90 30-45 | 172-345 552-862 207-345 241-621 241-621 207-310 | 55-35 30-10 55-35 50-30 50-30 55-35 | 70-60 60-30 70-60 65-50 65-50 ---- | 65-85B 90B-30C 65-85B 75-95B 75-95B 84B max. |
Average Room Temperature Tensile Data
| Form | Condition | Ultimate Tensile Strength, Ksi (MPa) | Yield Strength at 0.2% offset, Ksi (MPa) | Elongation in 2 in. (50.8mm) or 4D, percent |
| Sheet Plate Bar/Billet Sheet, Plate, Strip, Bar | Annealed Annealed Annealed Annealed | 98 (676) 95 (655) 95 (655) 80 (550)* | 42 (290) 41 (283) 41 (283) 35 (240)* | 40 45 45 30* |
* - minimum
| Sheet/Plate | Round Bar | Pipe | Tube | Fittings | Forgings |
| ASME SB-168 AMS 5540 | ASME SB-166 AMS 5665 | ASME SB-167 ASME SB-829 ASME SB-517 ASME SB-775 | ASME SB-163 ASME SB-516 ASME SB751 AMS 5580 | ASME SB-366 | ASME SB-564 AMS 5665 |
Applications
Some typical applications are:
- Barge and tank truck liners
- Carburizing atmospheres
- Ethylene dichloride crackers
- Furnace trays, mufflers, hangers
- Gasoline stabilizer production
- MgCl2 evaporates
- Phenol condensers
- Soap manufacture
- Titanium dioxide
- Vegetable and fatty acid vessels
OEM: We can produce according to custom's demand (Drawing or Smaple)
ODM: We can design according to your need
| Item | Inconel Sleeve |
| Material | Inconel600, inconel 601, inconel625, inconel690, inconel718,inconel750 |
| Size | 1/8", 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2",3", 4" |
| Standard | ANSI, ASME, DIN, JIS, BS |
| Pressure | 150lbs, 300lbs, 600lbs, 900lbs, 1500lbs, 2500lbs, 3000lbs, 5000lbs, 10000lbs, 15000lbs |
| Thread | NPT, BSPT, BSP, DIN2999, |
| Technology | Stainless Steel Rolling /Drawing + CNC machining |
| Application | water, gas, oil, chemical engineering, machine part , ... |
| Function | linkages of pipeline |
| Certification | ISO 9001:2000 |
| Packing | bubble bags/cartons/pallets or as to your request |
| MOQ | 30 pcs |
| Delivery | 30-60 Days |
| Payment | 1) 30% T/T down payment, the balance against the copy of B/L |
| 2) L/C | |
| 3) D/P | |
| Note | 1. No burr and sandhole |
| 2. Recyclable & Environmental | |
| 3. Thread test is implemented before shipment | |
| 4.Pneumatic pressure testing is performed on every fitting manufactured | |
| 5.Material chemical composition analysis by spectrometer on | |
| every furnace before casting is strictly executed |
