ASTM B111 UNS C70600 O61 Copper Nickel Tube , Cu90Ni10 Heat Exchanger Tube
Cu90Ni10 Seamless Copper Nickel Tube , ASTM B111 C70600 O61 Annealed Heat Exchanger Tube
UNS C70600 / Cu90Ni10 alloy tube primarily consists of approximately 90% copper (Cu) and 10% nickel (Ni). This combination of metals imparts the alloy with desirable properties such as high corrosion resistance and good thermal conductivity. The tube undergoes an annealing process, designated by "O61." Annealing involves heating the material and allowing it to cool gradually, which helps eliminate internal stresses, improve mechanical properties, and enhance workability. The annealing treatment in this alloy tube makes it more ductile and easier to form and shape during fabrication. Copper Alloy Tube finds application in various industries due to its unique properties, such as marine industry, oil and gas industry, power generation, HVAC and so on.
Copper Nickel Tube Specification
| Specification | ASTM B111, JIS H3300, BS EN 12451, EN 12449, GB/T8890 etc. |
| Material Grade |
C10100, C10200, C10300, C10800, C12000, C12200, C14200, C19200, C23000, C28000, C44300, C44400, C44500, C60800, C61300, C61400, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, And C72200 |
| Type | Seamless |
| Outer Diameter Size | 1/4" TO 1 1/4" 6.35 MM OD TO 114.3 MM OD |
| Wall Thickness | BWG 25,22,20,28,26,24,12,10 |
| Length | Single Random Length, Double Random Length And Customize Size |
| Pipe Ends | Plain Ends / Beveled Ends |
| Delivery Conditions | As Rolled, Cold Drawn, Hot Finish, Stress Relieved, Annealed, Hardened, Tempered |
| Available Testing | NACE MRO175, Hardness Test, Flare, Hydrostatic Test, Eddy Current test, Grain Size Test, Eddy Current, Annealed, Tempered, Stress Relieved etc. |
| ASTM B466 C70600 Copper Nickel Seamless Pipe & Tubes Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS etc. |
ASTM B111 UNS C70600 O61 Copper Nickel Tube
| Material Designation | Corresponding Material Symbol | ||||
| ASTM B111 | BS2871 | JIS H3300 | DIN1785 | GB/T 8890 | |
| Copper Nickel | C70600 | CN102 | C7060 | CuNi10Fe1Mn | BFe10-1-1 |
| C71500 | CN107 | C7150 | CuNi30Mn1Fe | BFe30-1-1 | |
| C71640 | CN108 | C7164 | CuNi30Fe2Mn2 | BFe30-2-2 | |
| C70400 | — | — | — | BFe5-1.5-0.5 | |
| — | — | — | — | B7 | |
| Aluminium Brass | C68700 | CZ110 | C6870 | CuZn20AL2 | HAL77-2 |
| Admiralty Brass | C44300 | CZ111 | C4430 | CuZn28Sn1 | HSn70-1 |
| Boric Brass | — | — | — | — | Hsn70-1B |
| — | — | — | — | Hsn70-1 AB | |
| Arsenical Brass | — | CZ126 | — | — | H68A |
| Brass Tube | C28000/C27200 | CZ108 | C2800/C2700 | CuZn36/CuZn37 | H65/H63 |
ASTM B111 UNS C70600 O61 Copper Nickel Tube Chemical Composition & Mechanical Properties
| Steel Grade | Cu | Sn | Al | As | Ni | Fe | Mn | Pb | Zn |
| C70400 | Remain | - | - | - | 4.8-6.2 | 1.3-1.7 | 0.3-0.8 | 0.05 max | 1.0 max |
| C70600 | Remain | - | - | - | 9.0-11.0 | 1.0-1.8 | 1.0 max | 0.05 max | 1.0 max |
| C71500 | Remain | - | - | - | 29.0-33.0 | 0.4-1.0 | 1.0 max | 0.05 max | 1.0 max |
| C71640 | Remain | - | - | - | 29.0-32.0 | 1.7-2.3 | 1.5-2.5 | 0.05 max | 1.0 max |
ASTM B111 UNS C70600 O61 Copper Nickel Tube Application
- Chillers
- Heat Condensers & Exchangers
- Power Plants
- Refineries
- Desalination Plants
- Ship Building & Ship Repairs
- Defence
- High Capacity Power Plants
- Distiller Tubes
- Evaporators & Ferrules
