SA210 Gr.A1 Seamless Medium-Carbon Steel Boiler And Superheater Tube, Cold Drawn And Normalized
SA210 Gr.A1 Seamless Medium-Carbon Steel Boiler And Superheater Tube, Cold Drawn And Normalized
Overview of SA210 Gr.A1 Seamless Tube
SA210 Gr.A1 Seamless Tube is a carbon steel boiler tube manufactured in accordance with ASTM A210/ASME SA210 standards. It is designed for high-temperature and medium-pressure service in boilers, superheaters, economizers, and heat exchangers. Produced by hot rolling or cold drawing, the tube features uniform wall thickness, good dimensional accuracy, and excellent surface quality. It offers reliable mechanical properties, high creep strength, good heat resistance, and satisfactory weldability, ensuring stable performance under long-term elevated temperature conditions. Common applications include power station boilers, industrial boilers, waste heat boilers, and pressure parts in thermal equipment.
The product is normally supplied in black finish with anti-rust oil, accompanied by material test certificates EN 10204 3.1. Strict non-destructive tests such as hydrostatic, ultrasonic, or eddy current inspection are conducted to guarantee quality and safety for pressure-containing service.
Core Features of SA210 Gr.A1 Seamless Tube
- High temperature stability: Long term service below 450°C, excellent resistance to creep and relaxation performance
- Seamless structure: hot-rolled/cold drawn manufacturing, no welds, pressure bearing, fatigue resistance, strong sealing performance
- Weldability: Moderate carbon content, good welding performance, suitable for boiler tube welding process
- Dimensional accuracy: Cold drawn pipes have stricter tolerances and better surface quality
| Standard Specification | ASTM A210 / A210M, ASME SA210, A210 A1, SA210 A1 |
| Grade | Grade A1 |
| Size Range | 1⁄2 in. to 6 in. [12.7 to 152.4mm] |
| Wall Thickness | 1.5mm - 25.4mm |
| Shape | Round |
| Manufacturing method | Hot and cold finished |
| Length | max 25 m, Single / Double random length |
| Terms | Mill test certificates will be issued according to EN10204-3.1 or 3.2 |
| A210 GR.A1 tubes Shall be Seamless, and the testing shall be as per A 450 / A450M. | |
| Common uses |
Power plant/industrial boiler, waste heat boiler, heat exchanger |
ASTM A210 / A210M Grade A1 Chemical Compositions
| Chemical Components (%) | ||||||||
| Grade | C | Si | Mn | P | S | Mo | Cr | V |
| A-1 | ≤0.27 | ≥0.10 | ≤0.93 | ≤0.035 | ≤0.035 | / | / | / |
ASTM A210 / A210M Grade A1 Mechanical Properties
| Mechanical Properties | ||||
| Grade | Tensile | Yield | Elongation | Hardness |
| Strength (Mpa) | Strength (Mpa) | (%) | (HRB) | |
| A-1 | ≥415 | ≥255 | ≥30 | ≤79 |
ASTM A210 / A210M Tube Wall Thickness Tolerance
|
Seamless Cold-Finished Tubes |
||
|
Outside Diameter |
Wall thickness Tolerance % |
|
|
In. (mm) |
Over (+) |
Under (-) |
|
1 ½ (38.1) and under |
20 |
0 |
|
Over 1½ (38.1) |
22 |
0 |
Ordering Information
- Quantity (feet, meters, or number of lengths)
- Name of material (seamless tubes),Grade
- Manufacture (hot-finished or cold-finished)
- Size (outside diameter and minimum wall thickness)
- Length (specific or random)
- Optional requirements
- Test report required (see section on Certification of Specification A 450/A 450M)
- Specification designation
- Special requirements
