COPPER ALLOY SMLS TUBE SB111 C44300 O61 ANNEALED ADMIRALTY BRASS
COPPER ALLOY SMLS TUBE SB111 C44300 O61 ANNEALED ADMIRALTY BRASS
Overview
Admiralty Brass Tubes is a zinc and copper-based alloy that contains minor amounts of arsenic and zinc. These tubes are recognized for their outstanding corrosion resistance in filthy river water, clean seawater, as well as slow-moving and stagnant water. Admiralty brass tubes are zinc-copper alloy with trace amounts of arsenic and zinc. These tubes are well-known for their great corrosion resistance in filthy river water, pure seawater, and slow-moving and stagnant water. The brass having 30% of zinc and tin of 1% and is inhibiting dezincification in several atmospheres and is widely used the material in tube manufacturing. There are many good features it possesses is high thermal conductivity, high strength, light-weight, corrosion-resistant etc. All of our tubes have a wide range of characteristics, including adaptability, corrosion resistance, increased thermal conductivity, ease of joining and installation, problem-free performance, and simple maintenance. We provide the option of customizing tubes with application-specific features to meet the needs of the coolers and evaporators business.The sector offers a wide selection of products to buyers, allowing for the fulfilment of all application requirements. The product is made available to buyers in a variety of sizes, wall thicknesses, grades, schedules, lengths, specifications, and standards. Along with the high quality of value-added and sales after-sales services, the product provided is priced reasonably.
ASTM B111 Equivalent Grade
| Material Designation | Corresponding Material Symbol | ||||
| GB/T8890 | ASTM B111 | BS2871 | JIS H3300 | DIN1785 | |
| Copper-Nickel | BFe10-1-1 | C70600 | CN102 | C7060 | CuNi10Fe1Mn |
| BFe30-1-1 | C71500 | CN107 | C7150 | CuNi30Mn1Fe | |
| (BFe30-2-2) | C71640 | CN108 | C7164 | CuNi30Fe2Mn2 | |
| (BFe5-1.5-0.5) | C70400 | – | – | – | |
| B7 | – | – | – | – | |
| Aluminums Brass | HAL77-2 | C68700 | CZ110 | C6870 | CuZn20Al2 |
| Admiralty Brass | HSn70-1 | C44300 | CZ111 | C4430 | CuZn28Sn1 |
| Boric Brass | Hsn70-18 | – | – | – | – |
| HSn70-1 AB | – | – | – | – | |
| Arsenical Brass | H68A | – | CZ126 | – | – |
| Brass Tube | H65/H63 | C28000/C27200 | CZ108 | C2800/C2700 | CuZn36/CuZn3 |
Mechanical properties
| Copper or Copper Alloy UNS NO. | Temper Designation | Tensile Strength, | Yield Strength, | |
| Standard | Former | min ksi | min ksi | |
| C44300 | O61 | annealed | 45 | 15 |
Chemical Composition
| Designation | Chemical Composition % | ||||||||
| Cu | Sn | Al | As | Ni | Fe | Mn | Pb max. | Zn | |
| C44300
C4430 CZ111 CuZn28Sn1 |
70.0-73.0 | 0.9-1.2 | – | 0.02-0.06 | – | 0.06max | – | 0.07 | Rem |
Application:
- Heat Exchangers
- Refineries
- Power Plants
- Desalination Plants
- Ship Building & Ship Repairs
- Condensers
- Ferrules
- Distillers
