Duplex Steel U Bend Tubes SA789 S32205 S31803 Heat Treatment Assurance
Overview
Duplex Steel is featured with a structure of two phases (α and γ) and has characteristics of both ferritic and austenitic stainless steel. It has good corrosion resistance and high strength. It is alloyed with 18%-28% Cr and 3%-10% Ni in the condition of low Carbon. Some steels also contain the alloy elements such as Mo, Cu, Nb, Ti and N, etc. Compared with ferritic stainless, duplex stainless steel has higher plasticity, ductility and better intergranular corrosion resistance and weldability. It keeps the same 475°C brittleness with ferritic stainless and high thermal conductivity. Duplex has improved yield strength, resistance to intergranular corrosion, stress corrosion, corrosion fatigue and abrasion & corrosion compared with austenitic stainless steel.
SA789 UNS 32205/Duplex 2205 Heat Exchanger Tubes are widely used for applications requiring heat transfer from one medium to another. These Heat Exchanger Tubes are effective in high temperature and pressure areas. U-Tubes are fixed with Tube Sheets with flow baffles and are placed in shell welded or bolted to the tube sheets. These Tubes have good mechanical properties, surface finishing and corrosion resistance. Our products are built with international production standards and maintain robustness, as well as precise finishing.
S32205 Chemical Composition
|
Composition |
Content |
|---|---|
|
Ni |
4.50 – 6.50 |
|
Fe |
63.72 min |
|
Cr |
22.0 – 23.0 |
|
C |
0.030 max |
|
Si |
1.00 max |
|
Mn |
2.00 max |
|
P |
0.030 max |
|
S |
0.020 max |
|
N |
0.14 – 0.20 |
S32205 Mechanical Properties
|
Grade |
S32205 |
|
Density (g/cm 3) |
7.805 |
|
Density (lb/in 3) |
0.285 |
|
Melting Point (°C) |
1420 – 1465 |
|
Melting Point (°F) |
2588 – 2669 |
Heat Exchanger U Tube Advantages:
- Superior surface finish
- Better mechanical property
- More precise dimension;
- Perfect inspection method and inspection equipment
Duplex Heat Exchanger Tubes Application:
- petroleum
- chemical industry
- electric power
- boiler
- high temperature resistant
- low temperature resistant
- corrosion resistant
