LU1S114 Magnetic RJ45 Jack WITH 10 / 100 BASE-TX MAGNETICS LPJ0120DNL

Price Negotiable

Price: Supportive

MOQ: 50/500/1000

Delivery Time: Stock

Brand: LINK-PP

Product Description

Competitor Cross Reference

Trader Part Number	Manufacturer Part Number	Manufacturer	Description
LU1S114	LPJ0013BBNL	LINk-PP	CONN MAGJACK 1PORT 10/100 BASE-T

Series	Connector Type	Applications	Mounting Type
Connectors, Interconnects	LINK-PP Rj45	10/100Base-T	Through Hole

Orientation	Termination	LED Color	Shielding
90° Angle (Right)	Solder	None	Shielded
Features RJ-45 connector integrated with Filter Size same as RJ-45 connector to save PCB board space Reduce EMI radiation, Improve EMI performance High performance for maximum EMI suppression. ISO9001,SGS,UL,CE,REACH Embedded mini PCI express Cellular modemfrom SierraWireless Reduce EMI radiation, Improve EMI performance Certified on all major carrier networks,attractive for network interface cards(NICS)Single port, Multi-port and Stackable configurations (Thru-hole/ SMT) Reduces the number of components to be placed on the board Frees up board space and offers signal protection Noise reduction in the system Improved reliability and optimal system performance Benefits of having shorter signal paths and the reliability gains from systems containing fewer components Helps manufacturers reach their goals of cost reduction
