China HFJT1-S101RL Rj45 Connector with 10Base-TX Integrated Magnetics LPJ1216CNL for sale

HFJT1-S101RL Rj45 Connector with 10Base-TX Integrated Magnetics LPJ1216CNL

Price Negotiable
Price: $0.05-$1.28
MOQ: 50/500/1000/25K
Delivery Time: Stock
Brand: LINK-PP
Product Description

HFJT1-S101RL Rj45 Connector with 10Base-TX Integrated Magnetics LPJ1216CNL



Competitor Cross Reference





Part Number

Manufacturer

Part Number

 Manufacturer Description

HFJT1-S101RL

LPJ1216CNL

 LINK-PP

HFJ11-S101E-S1LS21RL    RJ45 Modular Jack LPJ0215AANL 10Base-TX Network Connectors
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Rj45 10 Mbps Thru-Hole

Orientation Termination LED Color Shielding
90° Angle (Right) Solder None Shielded ,EMI-Finger



Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction

Related Part



HFJV1-1041RL LPJ0103GDNL HFJT1-S114-L11RL HFJV1-1041-L12RL
HFJV1-1041-L11RL LPJ0104GEM HFJT1-S114-L12RL HFJV1-1041-L21RL
LPJ0104GENL LPJ0155HENL HFJT1-S114-L17RL HFJV1-1043RL
LPJ0105HFNL LPJ0158GDNL HFJT1-S114-L21RL HFJV1-1043-L11RL
LPJ0108CNL LPJ0161BBNL HFJT1-S114-L51RL HFJV1-1043-L12RL
LPJ0111BBNL LPJ0162GDNL HFJT1-S114-L72RL HFJV1-1043-L21RL
LPJ0112ADNL LPJ0165ABNL HFJT1-1041RL HFJV1-1075RL
LPJ0112GDNL LPJ0172CNL HFJT1-1041-L11RL HFJV1-1075-L11RL
LPJ0112GENL LPJ0176GENL HFJT1-1041-L12RL HFJV1-1075-L12RL
LPJ0113ABNL LPJ0178ABNL HFJT1-1041-L21RL HFJV1-1075-L21RL
LPJ0113BBNL LPJ0182BANL LPJ0120DNL HFJV1-1081RL
LPJ0113CNL LPJ0182BBNL LPJ0125CNL HFJV1-1081-L11RL
LPJ0113DNL LPJ0183G28NL LPJ0127DNL LPJ0139GDNL
LPJ0114DNL LPJ0184NNL LPJ0132CNL LPJ0141GENL
HFJV1-1081-L12RL LPJ0188GDNL LPJ0134ABNL LPJ0143HENL
HFJV1-1081-L21RL LPJ0194CNL LPJ0135GDNL LPJ0147AENL
HFJT1-S101RL LPJ0195CNL LPJ0138GDNL LPJ0148HENL
HFJT1-S101-L11RL LPJ0196AGNL LPJ0516CNL LPJ0151GDNL
HFJT1-S101-L12RL LPJ0211BBNL LPJ0520CNL HFJT1-1043RL
HFJT1-S101-L17RL LPJ0215AANL HFJT1-S101-L72RL HFJT1-1043-L11RL
HFJT1-S101-L21RL LPJ0215CNL HFJT1-S114RL HFJT1-1043-L12RL
HFJT1-S101-L51RL LPJ0215DNL HFJT1-1075-L11RL HFJT1-1043-L21RL



HFJT1-S101RL Rj45 Connector with 10Base-TX Integrated Magnetics LPJ1216CNL
