Pulse Magnetic RJ45 JX10-0061NL Connector 10/100BT Female Jack

JX10-0061NL TEST NOTES(25±5℃)
1.TR:(100KHz,0.1V);
  TX=1CT:1CT  ±3%      RX=1CT:1CT  ±3%P2.OCL:(100KHz,100mV,8mA,DC Bias)
  PINS:(P1,P2),(P7,P8)=350uH MIN
3.HIPOT:
  PINS(P1,P3,P2)TO (J1,J2)=1500VAC FOR 60 SECONDS
  PINS(P7,P6,P8)TO (J3,J6)=1500VAC FOR 60 SECONDS
4.INSERTION LOSS:
  -1.0dB MAX @ 0.3MHz TO 100MHz
5.RETURN LOSS:
  -20dB MIN @ 1MHz TO 10MHz
  -16dB MIN @ 10MHz TO 30MHz
  -12dB MIN @ 30MHz TO 60MHz
  -10dB MIN @ 60MHz TO 100MHz
6.CROSS TALK:
  -40dB MIN @ 1MHz TO 30MHz
  -35dB MIN @ 30MHz TO 60MHz
  -30dB MIN @ 60MHz TO 100MHz
7.COMMON TO COMMON MODE REJECTION:
  -30dB MIN @ 1MHz TO 50MHz
  -20dB MIN @ 50MHz TO 150MHz
8.OPERATING TEMPERATURE: -40℃～+85℃.
