H5009FNL Gigabit Ethernet Transformer LP5015ANL Single Port 10/100/1000Mbps
Price:
$0.06-$3.2
MOQ:
400/2000/10K/25K
Delivery Time:
Stock
Brand:
LINK-PP
Product Description
H5009FNL Gigabit Ethernet Transformer LP5015ANL Single Port 10/100/1000Mbps
- LINK-PP LP5015ANL 10/100/1000Base-T Filter Magnetic
- Cross H5009FNL Pulse Transformer
- Gigabit Ethernet Transformer Connection Single Port Transformer Module
- 24Pins Surface Mounting
| Single Port, 1000 BASE-T Ethernet Transformer Modules, SMD,Rohs | |
| LINK-PP Part Number | LP5015ANL |
| Speed | 1000BASE-T |
| Number of Ports | SINGLE |
| Application - LAN | ETHERNET (NoN PoE) |
| Package | SMD |
| Temperature | - 40 TO + 85 |
| AutomDX | YES |
| Comment | SAME AS NL VERSION |
| Configuration RX | T,C,S |
| Configuration TX | T,C,S |
| Construction | OPEN FRAME |
| Cores Per Port | 8 |
| Package Height (Inches) | 0.225 |
| Package Height (mm) | 5.72 |
| Package Length (Inches) | 0.740 |
| Package Length (mm) | 18.80 |
| Package Width (Inches) | 0.537 |
| Package Width (mm) | 13.64 |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
 |
Electrical Specification @25℃ 1.OCL(100KHz,0.1Vrms,8mA):350uH 2.Turns Ratio: 1CT:1CT 3.Insertion Loss: 1-100MHz:-1.0dB max 4.Return Loss(dB min): 1-40MHz:-18 60MHz:-14 80MHz:-12 100MHz:-10 5.Crosstalk(dB min): 30MHz:-43 60MHz:-37 100MHz:-33 6.CMR: 0.1-100MHz:-40dB typ 7.Isolation Voltage: 1500Vrms 8.Operating Temperature: -40℃～+85℃. |
H5009FNL Gigabit Ethernet Transformer LP5015ANL Single Port 10/100/1000Mbps
