China JKM-0011NL RJ45 Jack With Integrated Magnetics Telecom Connectors LPJ0011DNL for sale

JKM-0011NL RJ45 Jack With Integrated Magnetics Telecom Connectors LPJ0011DNL

Price Negotiable
Price: Supportive&Discount
MOQ: 50/500/1000
Delivery Time: Stock
Brand: LINK-PP
Product Description
JKM-0011NL , LPJ0011DNL RJ45 With Integrated Magnetics Telecom Connectors
  • 1X1 Latch-Down RJ45 LPJ0011DNL 10/100Mbps Fast Ethernet
  • Transformer RJ45 8P8C pin Integrated Magnetics Connector
  • Cross Equivalent JKM-0011NL Pin to Pin Replace Cost-Effective
  • Meets IEEE802.3 specification
  • 350μH minimum OCL with 8mA DC bias current
  • Temperature range from 0℃ TO 70℃





ELECTRICAL SPECFICATIONS @25℃
1.Turn Ratio(±2%): 1CT:1CT
2.Inductance OCL: 350uH MIN
@100KHz/0.1V,8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 0.3-100MHz
-1.5dB MAX @100-125MHz
4.Return Loss:
-15dB MIN @ 40MHz
-13.1dB MIN @ 50MHz
-12dB MIN @ 60-80MHz
-10dB MIN @ 100MHz
5.Cross talk:
-45dB MIN @ 30MHz
-40dB MIN @ 60MHz
-35dB MIN @ 100MHz
6.Common Mode Rejection:
-43dB MIN @ 30MHz
-37dB MIN @ 80MHz
-33dB MIN @ 100MHz
7.CMRR: -30dB Min @1-100MHz
8.Hipot Test: 1500Vrms MIN
9.Operating Temperature Range: 0℃ TO 70℃
