SI-50075-F , LPJK0071A8NL Magnetic RJ45 Jack 1 x 10/100/1000BASE-TX
Price:
Supportive
MOQ:
50/500/1000
Delivery Time:
Stock
Brand:
LINK-PP
Product Description
SI-50075-F , LPJK0071A8NL Magnetic RJ45 Jack 1 x 10/100/1000BASE-TX
- 1 x 10/100/1000BASE-TX (Uplink ports): LPJK0071A8NL , Side Entry Rj45 Magnetics
- Specification Cross SI-50075-F Equivalent
- LED Indicator 1x 10/100/1000 AutoMDIX compatible
- 0℃ TO 70℃ : LPJK0071A8NL
- -40 TO +85℃: LPJK4071A8NL
- 350uH min OCL at 8mA DC Bias
- 6μ” Gold Plating (min) on Contacts
- Full Temp Range ,100% Electrical Testing
- 1500Vrms Hi-Pot
| Turn Ratio(±2%): | TX=1CT:1CT RX=1CT:CT |  |
| Inductance OCL | 350uH MIN/@ 100KHz,0.1V,8mA DC Bias | |
| Insertion Loss | -1.0dB MAX @ 1-65MHz | |
| Return Loss | -20dB MIN @ 1-10MHz | |
| -16dB MIN @ 10-30MHz | ||
| -12dB MIN @ 30-60MHz | ||
| -10dB MIN @ 60-100MHz | ||
| Cross talk | -40dB MIN @ 1-30MHz | |
| -35dB MIN @ 30-60MHz | ||
| -30dB MIN @ 60-100MHz | ||
| Common Mode Rejection | -30dB MIN @ 1-50MHz | |
| -20dB MIN @ 50-150MHz | ||
| Hipot Test | 1500Vrms MIN | |
| Operating Temperature | -40℃ TO 85℃ |
